APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP

GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-27

0x010F 0x8000 PH IOC3 LOW B BLK F001 R 1

0x010F 0x0001 PH IOC3 LOW C BLK F001 R 1

0x010F 0x0002 PH IOC3 LOW A PKP F001 R 1

0x010F 0x0004 PH IOC3 LOW A OP F001 R 1

0x010F 0x0008 PH IOC3 LOW B PKP F001 R 1

0x010F 0x0010 PH IOC3 LOW B OP F001 R 1

0x010F 0x0020 PH IOC3 LOW C PKP F001 R 1

0x010F 0x0040 PH IOC3 LOW C OP F001 R 1

0x010F 0x0080 PH IOC3 LOW PKP F001 R 1

0x0110 0x0100 PH IOC3 LOW OP F001 R 1

Estados Sobreintensidad instantánea de Neutro - Neutral IOC States

0x0115 0x0200 NEUTRAL IOC1 BLOCK F001 R 1

0x0115 0x0400 NEUTRAL IOC1 PKP F001 R 1

0x0115 0x0800 NEUTRAL IOC1 OP F001 R 1

0x011A 0x1000 NEUTRAL IOC2 BLOCK F001 R 1

0x011A 0x2000 NEUTRAL IOC2 PKP F001 R 1

0x011A 0x4000 NEUTRAL IOC2 OP F001 R 1

0x011F 0x8000 NEUTRAL IOC3 BLOCK F001 R 1

0x011F 0x0001 NEUTRAL IOC3 PKP F001 R 1

0x011F 0x0002 NEUTRAL IOC3 OP F001 R 1

Estados Sobreintensidad instantánea de Tierra - Ground IOC States

0x0124 0x0004 GROUND IOC1 BLOCK F001 R 1

0x0124 0x0008 GROUND IOC1 PKP F001 R 1

0x0124 0x0010 GROUND IOC1 OP F001 R 1

0x0129 0x0020 GROUND IOC2 BLOCK F001 R 1

0x0129 0x0040 GROUND IOC2 PKP F001 R 1

0x0129 0x0080 GROUND IOC2 OP F001 R 1

0x012F 0x0100 GROUND IOC3 BLOCK F001 R 1

0x012F 0x0200 GROUND IOC3 PKP F001 R 1

0x012F 0x0400 GROUND IOC3 OP F001 R 1

Estados Sobreintensidad instantánea de Tierra Sensible - Sensitive Ground IOC States

0x0134 0x0800 SENS GND IOC1 BLK F001 R 1

0x0134 0x1000 SENS GND IOC1 PKP F001 R 1

0x0134 0x2000 SENS GND IOC1 OP F001 R 1

0x0139 0x4000 SENS GND IOC2 BLK F001 R 1

0x0139 0x8000 SENS GND IOC2 PKP F001 R 1

0x0139 0x0001 SENS GND IOC2 OP F001 R 1

0x013E 0x0002 SENS GND IOC3 BLK F001 R 1

0x013E 0x0004 SENS GND IOC3 PKP F001 R 1

0x013E 0x0008 SENS GND IOC3 OP F001 R 1

Estados Sobreintensidad Temporizada de Fases Nivel Alto - Phase TOC High States

0x0143 0x0010 PH TOC1 HIGH A BLK F001 R 1

0x0143 0x0020 PH TOC1 HIGH B BLK F001 R 1

0x0143 0x0040 PH TOC1 HIGH C BLK F001 R 1

0x0143 0x0080 PH TOC1 HIGH A PKP F001 R 1

0x0144 0x0100 PH TOC1 HIGH A OP F001 R 1

0x0144 0x0200 PH TOC1 HIGH B PKP F001 R 1

0x0144 0x0400 PH TOC1 HIGH B OP F001 R 1

0x0144 0x0800 PH TOC1 HIGH C PKP F001 R 1

0x0144 0x1000 PH TOC1 HIGH C OP F001 R 1

ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
