B-28 F650 DIGITAL BAY CONTROLLER GEK-106310-AF

B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL

0x0144 0x2000 PH TOC1 HIGH PKP F001 R 1

0x0144 0x4000 PH TOC1 HIGH OP F001 R 1

0x0149 0x8000 PH TOC2 HIGH A BLK F001 R 1

0x0149 0x0001 PH TOC2 HIGH B BLK F001 R 1

0x0149 0x0002 PH TOC2 HIGH C BLK F001 R 1

0x0149 0x0004 PH TOC2 HIGH A PKP F001 R 1

0x0149 0x0008 PH TOC2 HIGH A OP F001 R 1

0x0149 0x0010 PH TOC2 HIGH B PKP F001 R 1

0x0149 0x0020 PH TOC2 HIGH B OP F001 R 1

0x0149 0x0040 PH TOC2 HIGH C PKP F001 R 1

0x0149 0x0080 PH TOC2 HIGH C OP F001 R 1

0x014A 0x0100 PH TOC2 HIGH PKP F001 R 1

Estados Sobreintensidad Temporizada de Fases Nivel Alto - Phase TOC High States(cont.)

0x014A 0x0200 PH TOC2 HIGH OP F001 R 1

0x014F 0x0400 PH TOC3 HIGH A BLK F001 R 1

0x014F 0x0800 PH TOC3 HIGH B BLK F001 R 1

0x014F 0x1000 PH TOC3 HIGH C BLK F001 R 1

0x014F 0x2000 PH TOC3 HIGH A PKP F001 R 1

0x014F 0x4000 PH TOC3 HIGH A OP F001 R 1

0x014F 0x8000 PH TOC3 HIGH B PKP F001 R 1

0x014F 0x0001 PH TOC3 HIGH B OP F001 R 1

0x014F 0x0002 PH TOC3 HIGH C PKP F001 R 1

0x014F 0x0004 PH TOC3 HIGH C OP F001 R 1

0x014F 0x0008 PH TOC3 HIGH PKP F001 R 1

0x014F 0x0010 PH TOC3 HIGH OP F001 R 1

Estados Sobreintensidad Temporizada de Neutro - Neutral TOC States

0x0154 0x0020 NEUTRAL TOC1 BLOCK F001 R 1

0x0154 0x0040 NEUTRAL TOC1 PKP F001 R 1

0x0154 0x0080 NEUTRAL TOC1 OP F001 R 1

0x015A 0x0100 NEUTRAL TOC2 BLOCK F001 R 1

0x015A 0x0200 NEUTRAL TOC2 PKP F001 R 1

0x015A 0x0400 NEUTRAL TOC2 OP F001 R 1

0x015F 0x0800 NEUTRAL TOC3 BLOCK F001 R 1

0x015F 0x1000 NEUTRAL TOC3 PKP F001 R 1

0x015F 0x2000 NEUTRAL TOC3 OP F001 R 1

Estados Sobreintensidad Temporizada de Tierra - Ground TOC States

0x0164 0x4000 GROUND TOC1 BLOCK F001 R 1

0x0164 0x8000 GROUND TOC1 PKP F001 R 1

0x0164 0x0001 GROUND TOC1 OP F001 R 1

0x0169 0x0002 GROUND TOC2 BLOCK F001 R 1

0x0169 0x0004 GROUND TOC2 PKP F001 R 1

0x0169 0x0008 GROUND TOC2 OP F001 R 1

0x016E 0x0010 GROUND TOC3 BLOCK F001 R 1

0x016E 0x0020 GROUND TOC3 PKP F001 R 1

0x016E 0x0040 GROUND TOC3 OP F001 R 1

Estados Sobreintensidad Temporizada Tierra Sensible - Sentive Ground TOC States

0x0173 0x0080 SENS GND TOC1 BLOCK F001 R 1

0x0174 0x0100 SENS GND TOC1 PKP F001 R 1

0x0174 0x0200 SENS GND TOC1 OP F001 R 1

0x0179 0x0400 SENS GND TOC2 BLOCK F001 R 1

ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
