B-32 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
Estados Fallo de Fusible - Fuse failure States
0x01EB 0x0100 VT FUSE FAILURE F001 R 1
Estados Unidad de Sincronismo - Synchrocheck States
0x01F0 0x0200 Synchrocheck BLK INP F001 R 1
0x01F0 0x0400 Synchrocheck OP F001 R 1
0x01F0 0x0800 SYNCHK CLOSE PERM F001 R 1
0x01F0 0x1000 Synchrocheck COND OP F001 R 1
0x01F0 0x2000 DL-DB OPERATION F001 R 1
0x01F0 0x4000 DL-LB OPERATION F001 R 1
0x01F0 0x8000 LL-DB OPERATION F001 R 1
0x01F0 0x0001 SLIP CONDITION F001 R 1
0x01F0 0x0002 BUS FREQ > LINE FREQ F001 R 1
0x01F0 0x0004 BUS FREQ < LINE FREQ F001 R 1
Estados Reenganchador (bit) - Autorecloser States
0x01F5 0x0008 AR LEVEL BLOCK F001 R 1
0x01F5 0x0010 AR PULSE BLOCK F001 R 1
0x01F5 0x0020 AR PULSE UNBLOCK F001 R 1
0x01F5 0x0080 AR INITIATE F001 R 1
0x01F6 0x0100 AR CONDS INPUT F001 R 1
0x01F6 0x0200 AR CLOSE BREAKER F001 R 1
0x01F6 0x0400 AR OUT OF SERVICE F001 R 1
0x01F6 0x0800 AR READY F001 R 1
0x01F6 0x1000 AR LOCKOUT F001 R 1
0x01F6 0x2000 AR BLOCK F001 R 1
0x01F6 0x4000 AR RCL IN PROGRESS F001 R 1
0x01F6 0x8000 AR LCK BY ANOMALY F001 R 1
0x01F6 0x0001 AR LCK BY FAIL OPEN F001 R 1
0x01F6 0x0002 AR LCK BY FAIL CLOSE F001 R 1
0x01F6 0x0004 AR LCK BY USER F001 R 1
0x01F6 0x0008 AR LCK BY CONDS F001 R 1
0x01F6 0x0010 AR LCK BY TRIPS F001
R 1
0x01F6 0x0020 AR LCK BY SHOTS F001 R 1
0x01F6 0x0040 AR BLK AFTER 1 SHOT F001 R 1
0x01F6 0x0080 AR BLK AFTER 2 SHOT F001 R 1
0x01F7 0x0100 AR BLK AFTER 3 SHOT F001 R 1
0x01F7 0x0200 AR BLK AFTER 4 SHOT F001 R 1
0x01F7 0x0400 AR BLOCK BY LEVEL F001 R 1
0x01F7 0x0800 AR BLOCK BY PULSE F001 R 1
Estados Sobretensión de Neutro Nivel Alto - Neutral OV High States
0x01FC 0x1000 NEUTRAL OV1 HIGH BLK F001 R 1
0x01FC 0x2000 NEUTRAL OV1 HIGH PKP F001 R 1
0x01FC 0x4000 NEUTRAL OV1 HIGH OP F001 R 1
0x0201 0x8000 NEUTRAL OV2 HIGH BLK F001 R 1
0x0201 0x0001 NEUTRAL OV2 HIGH PKP F001 R 1
0x0201 0x0002 NEUTRAL OV2 HIGH OP F001 R 1
0x0206 0x0004 NEUTRAL OV3 HIGH BLK F001 R 1
0x0206 0x0008 NEUTRAL OV3 HIGH PKP F001 R 1
0x0206 0x0010 NEUTRAL OV3 HIGH OP F001 R 1
Estados Sobretensión de Neutro Nivel Bajo - Neutral OV Low States
0x020B 0x0020 NEUTRAL OV1 LOW BLK F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
