APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-33
0x020B 0x0040 NEUTRAL OV1 LOW PKP F001 R 1
0x020B 0x0080 NEUTRAL OV1 LOW OP F001 R 1
0x0211 0x0100 NEUTRAL OV2 LOW BLK F001 R 1
0x0211 0x0200 NEUTRAL OV2 LOW PKP F001 R 1
0x0211 0x0400 NEUTRAL OV2 LOW OP F001 R 1
0x0216 0x0800 NEUTRAL OV3 LOW BLK F001 R 1
0x0216 0x1000 NEUTRAL OV3 LOW PKP F001 R 1
0x0216 0x2000 NEUTRAL OV3 LOW OP F001 R 1
Estados Subtensión Auxiliar - Auxiliary UV States
0x021B 0x4000 AUXILIARY UV1 BLOCK F001 R 1
0x021B 0x8000 AUXILIARY UV1 PKP F001 R 1
0x021B 0x0001 AUXILIARY UV1 OP F001 R 1
0x0220 0x0002 AUXILIARY UV2 BLOCK F001 R 1
0x0220 0x0004 AUXILIARY UV2 PKP F001 R 1
0x0220 0x0008 AUXILIARY UV2 OP F001 R 1
0x0225 0x0010 AUXILIARY UV3 BLOCK F001 R 1
0x0225 0x0020 AUXILIARY UV3 PKP F001 R 1
0x0225 0x0040 AUXILIARY UV3 OP F001 R 1
Estados Sobretensión de Fases - Phase OV States
0x022A 0x0080 PHASE OV1 BLOCK F001 R 1
0x022B 0x0100 PHASE OV1 AB PKP F001 R 1
0x022B 0x0200 PHASE OV1 AB OP F001 R 1
0x022B 0x0400 PHASE OV1 BC PKP F001 R 1
0x022B 0x0800 PHASE OV1 BC OP F001 R 1
0x022B 0x1000 PHASE OV1 CA PKP F001 R 1
0x022B 0x2000 PHASE OV1 CA OP F001 R 1
0x022B 0x4000 PHASE OV1 PKP F001 R 1
0x022B 0x8000 PHASE OV1 OP F001 R 1
0x0230 0x0001 PHASE OV2 BLOCK F001 R 1
0x0230 0x0002 PHASE OV2 AB PKP F001 R 1
0x0230 0x0004 PHASE OV2 AB OP F001 R 1
0x0230 0x0008 PHASE OV2 BC PKP F001 R 1
0x0230 0x0010 PHASE OV2 BC OP F001 R 1
0x0230 0x0020 PHASE OV2 CA PKP F001 R 1
0x0230 0x0040 PHASE OV2 CA OP F001 R 1
0x0230 0x0080 PHASE OV2 PKP F001
R 1
0x0231 0x0100 PHASE OV2 OP F001 R 1
0x0236 0x0200 PHASE OV3 BLOCK F001 R 1
0x0236 0x0400 PHASE OV3 AB PKP F001 R 1
0x0236 0x0800 PHASE OV3 AB OP F001 R 1
0x0236 0x1000 PHASE OV3 BC PKP F001 R 1
0x0236 0x2000 PHASE OV3 BC OP F001 R 1
0x0236 0x4000 PHASE OV3 CA PKP F001 R 1
0x0236 0x8000 PHASE OV3 CA OP F001 R 1
0x0236 0x0001 PHASE OV3 PKP F001 R 1
0x0236 0x0002 PHASE OV3 OP F001 R 1
Estados Sobretensión Auxiliar - Auxiliary OV States
0x023B 0x0004 AUXILIARY OV1 BLOCK F001 R 1
0x023B 0x0008 AUXILIARY OV1 PKP F001 R 1
0x023B 0x0010 AUXILIARY OV1 OP F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
