B-34 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x0240 0x0020 AUXILIARY OV2 BLOCK F001 R 1
0x0240 0x0040 AUXILIARY OV2 PKP F001 R 1
0x0240 0x0080 AUXILIARY OV2 OP F001 R 1
0x0246 0x0100 AUXILIARY OV3 BLOCK F001 R 1
0x0246 0x0200 AUXILIARY OV3 PKP F001 R 1
0x0246 0x0400 AUXILIARY OV3 OP F001 R 1
Estados Sobreintensidad Temporizada de Secuencia Negativa - Negative Sequence TOC States
0x024B 0x0800 NEG SEQ TOC1 BLOCK F001 R 1
0x024B 0x1000 NEG SEQ TOC1 PKP F001 R 1
0x024B 0x2000 NEG SEQ TOC1 OP F001 R 1
0x0250 0x4000 NEG SEQ TOC2 BLOCK F001 R 1
0x0250 0x8000 NEG SEQ TOC2 PKP F001 R 1
0x0250 0x0001 NEG SEQ TOC2 OP F001 R 1
0x0255 0x0002 NEG SEQ TOC3 BLOCK F001 R 1
0x0255 0x0004 NEG SEQ TOC3 PKP F001 R 1
0x0255 0x0008 NEG SEQ TOC3 OP F001 R 1
Estados Sobrefrecuencia - Overfrequency States
0x025A 0x0010 OVERFREQ1 BLOCK F001 R 1
0x025A 0x0020 OVERFREQ1 PKP F001 R 1
0x025A 0x0040 OVERFREQ1 OP F001 R 1
0x025F 0x0080 OVERFREQ2 BLOCK F001 R 1
0x0260 0x0100 OVERFREQ2 PKP F001 R 1
0x0260 0x0200 OVERFREQ2 OP F001 R 1
0x0265 0x0400 OVERFREQ3 BLOCK F001 R 1
0x0265 0x0800 OVERFREQ3 PKP F001 R 1
0x0265 0x1000 OVERFREQ3 OP F001 R 1
Estados Subfrecuencia - Underfrequency States
0x026A 0x2000 UNDERFREQ1 BLOCK F001 R 1
0x026A 0x4000 UNDERFREQ1 PKP F001 R 1
0x026A 0x8000 UNDERFREQ1 OP F001 R 1
0x026F 0x0001 UNDERFREQ2 BLOCK F001 R 1
0x026F 0x0002 UNDERFREQ2 PKP F001 R 1
0x026F 0x0004 UNDERFREQ2 OP F001 R 1
0x0274 0x0008 UNDERFREQ3 BLOCK F001 R 1
0x0274 0x0010 UNDERFREQ3 PKP F001 R 1
0x0274 0x0020 UNDERFREQ3 OP F001 R 1
0x04D9 0x0001 OVERFREQ5 BLOCK F001 R 1
0x04D9 0x0002 OVERFREQ5 PKP F001 R 1
0x04D9 0x0004 OVERFREQ5 OP F001 R 1
0x04DA 0x0001 UNDERFREQ5 BLOCK F001 R 1
0x04DA 0x0002 UNDERFREQ5 PKP F001 R 1
0x04DA 0x0004 UNDERFREQ5 OP F001 R 1
0x04DB 0x0001 OVERFREQ6 PKP F001 R 1
0x04DB 0x0002 OVERFREQ6 OP F001 R 1
0x04DB 0x0004 UNDERFREQ6 BLOCK F001
R 1
0x04DC 0x0001 UNDERFREQ6 PKP F001 R 1
0x04DC 0x0002 UNDERFREQ6 OP F001 R 1
0x04DC 0x0004 OVERFREQ5 PKP F001 R 1
Estados de 60CTs- 60CTs Failure States
0x04DD 0x0002 CT Failure PKP F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
