APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-35
0x04DD 0x0004 CT Failure OP F001 R 1
0x04DD 0x0008 CT Failure BLOCK F001 R 1
Estados de Inhibición por 2nd armónico- 2nd Harmonic Inhibit States
0x04DE 0x0002 2nd HRMC PKP F001 R 1
0x04DE 0x0004 2nd HRMC OP F001 R 1
0x04DE 0x0008 2nd HRMC BLOCK F001 R 1
Estados Calibración - Calibration States
0x0279 0x0040 FACTORY CALIBRATION F001 R 1
0x0279 0x0080 CALIBRATION ERROR F001 R 1
Estados Oscilografía - Oscillography States
0x027A 0x0100 OSC DIG CHANNEL 1 F001 R 1
0x027A 0x0200 OSC DIG CHANNEL 2 F001 R 1
0x027A 0x0400 OSC DIG CHANNEL 3 F001 R 1
0x027A 0x0800 OSC DIG CHANNEL 4 F001 R 1
0x027A 0x1000 OSC DIG CHANNEL 5 F001 R 1
0x027A 0x2000 OSC DIG CHANNEL 6 F001 R 1
0x027A 0x4000 OSC DIG CHANNEL 7 F001 R 1
0x027A 0x8000 OSC DIG CHANNEL 8 F001 R 1
0x027A 0x0001 OSC DIG CHANNEL 9 F001 R 1
0x027A 0x0002 OSC DIG CHANNEL 10 F001 R 1
0x027A 0x0004 OSC DIG CHANNEL 11 F001 R 1
0x027A 0x0008 OSC DIG CHANNEL 12 F001 R 1
0x027A 0x0010 OSC DIG CHANNEL 13 F001 R 1
0x027A 0x0020 OSC DIG CHANNEL 14 F001 R 1
0x027A 0x0040 OSC DIG CHANNEL 15 F001 R 1
0x027A 0x0080 OSC DIG CHANNEL 16 F001 R 1
0x027B 0x0100 OSCILLO TRIGGER F001
R 1
Estados Localizador de Faltas - Fault Report States
0x0280 0x0200 FAULT REPORT TRIGG F001 R 1
0x0280 0x0400 CLEAR FAULT REPORTS F001 R 1
Agrupamiento de Funciones - Group States
0x028F 0x0400 GROUP 1 ACT ON F001 R 1
0x028F 0x0800 GROUP 2 ACT ON F001 R 1
0x028F 0x1000 GROUP 3 ACT ON F001 R 1
0x028F 0x2000 SETT GROUPS BLOCK F001 R 1
0x028F 0x4000 GROUP 1 BLOCKED F001 R 1
0x028F 0x8000 GROUP 2 BLOCKED F001 R 1
0x028F 0x0001 GROUP 3 BLOCKED F001 R 1
Canal por defecto - Default Channel (not used)
0x0294 0x0002 Default Channel F001 R 1
Estados Unidad de Conductor Roto - Broken Conductor
0x0294 0x0004 BROKEN CONDUCT1 BLK F001 R 1
0x0294 0x0008 BROKEN CONDUCT1 PKP F001 R 1
0x0294 0x0010 BROKEN CONDUCT1 OP F001 R 1
0x0299 0x0020 BROKEN CONDUCT2 BLK F001 R 1
0x0299 0x0040 BROKEN CONDUCT2 PKP F001 R 1
0x0299 0x0080 BROKEN CONDUCT2 OP F001 R 1
0x029F 0x0100 BROKEN CONDUCT3 BLK F001 R 1
0x029F 0x0200 BROKEN CONDUCT3 PKP F001 R 1
0x029F 0x0400 BROKEN CONDUCT3 OP F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
