B-38 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x0369 0x8000 PH TOC2 LOW B BLK F001 R 1
0x0369 0x0001 PH TOC2 LOW C BLK F001 R 1
0x0369 0x0002 PH TOC2 LOW A PKP F001 R 1
0x0369 0x0004 PH TOC2 LOW A OP F001 R 1
0x0369 0x0008 PH TOC2 LOW B PKP F001 R 1
Estados Sobrecorriente Temporizada de Fases Nivel Bajo - Phase TOC Low States(cont.)
0x0369 0x0010 PH TOC2 LOW B OP F001 R 1
0x0369 0x0020 PH TOC2 LOW C PKP F001 R 1
0x0369 0x0040 PH TOC2 LOW C OP F001 R 1
0x0369 0x0080 PH TOC2 LOW PKP F001 R 1
0x036A 0x0100 PH TOC2 LOW OP F001 R 1
0x036F 0x0200 PH TOC3 LOW A BLK F001 R 1
0x036F 0x0400 PH TOC3 LOW B BLK F001 R 1
0x036F 0x0800 PH TOC3 LOW C BLK F001 R 1
0x036F 0x1000 PH TOC3 LOW A PKP F001 R 1
0x036F 0x2000 PH TOC3 LOW A OP F001 R 1
0x036F 0x4000 PH TOC3 LOW B PKP F001 R 1
0x036F 0x8000 PH TOC3 LOW B OP F001 R 1
0x036F 0x0001 PH TOC3 LOW C PKP F001 R 1
0x036F 0x0002 PH TOC3 LOW C OP F001 R 1
0x036F 0x0004 PH TOC3 LOW PKP F001 R 1
0x036F 0x0008 PH TOC3 LOW OP F001 R 1
Estados Contactos Configuración Aparamenta (16 elementos) - Switchgear Contact Configuration States
0x0374 0x0010 SWITCH 1 A INPUT F001 R 1
0x0374 0x0020 SWITCH 1 B INPUT F001 R 1
0x0374 0x0040 SWITCH 2 A INPUT F001 R 1
0x0374 0x0080 SWITCH 2 B INPUT F001 R 1
... ... ... ... ... ... ... ...
0x0376 0x0004 SWITCH 16 A INPUT F001 R 1
0x0376 0x0008 SWITCH 16 B INPUT F001 R 1
Estados Contactos Aparamenta (16 elementos) - Switchgear Contact States
0x0376 0x0010 SWITCH 1 A STATUS F001 R 1
0x0376 0x0020 SWITCH 1 B STATUS F001 R 1
0x0376 0x0040 SWITCH 2 A STATUS F001 R 1
0x0376 0x0080 SWITCH 2 B STATUS F001 R 1
... ... ... ... ... ... ... ...
0x0378 0x0004 SWITCH 16 A STATUS F001 R 1
0x0378 0x0008 SWITCH 16 B STATUS F001 R 1
Estados Aparamenta (16 elementos) - Switchgear States
0x0378 0x0010 SWITCH 1 OPEN F001 R 1
0x0378 0x0020 SWITCH 1 CLOSED F001 R 1
0x0378 0x0040 SWITCH 1 00_ERROR F001 R 1
0x0378 0x0080 SWITCH 1 11_ERROR F001 R 1
0x0379 0x0100 SWITCH 2 OPEN F001 R 1
0x0379 0x0200 SWITCH 2 CLOSED F001 R 1
0x0379 0x0400 SWITCH 2 00_ERROR F001 R 1
0x0379 0x0800 SWITCH 2 11_ERROR F001 R 1
... ... ... ... ... ... ... ...
0x037C 0x0001 SWITCH 16 OPEN F001 R 1
0x037C 0x0002 SWITCH 16 CLOSED F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
