APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-39
0x037C 0x0004 SWITCH 16 00_ERROR F001 R 1
0x037C 0x0008 SWITCH 16 11_ERROR F001 R 1
Estados Inicio Apertura y Cierre Aparamenta - Switchgear Open-Close Initializing States
0x037C 0x0010 SWITCH 1 OPEN INIT F001 R 1
0x037C 0x0020 SWITCH 1 CLOSE INIT F001 R 1
0x037C 0x0040 SWITCH 2 OPEN INIT F001 R 1
0x037C 0x0080 SWITCH 2 CLOSE INIT F001 R 1
... ... ... ... ... ... ... ...
0x037E 0x0004 SWITCH 16 OPEN INIT F001 R 1
0x037E 0x0008 SWITCH 16 CLOSE INIT F001 R 1
Estados Fallo Apertura y Cierre Aparamenta - Switchgear Fail States
0x037E 0x0010 SWGR 1 FAIL TO OPEN F001 R 1
0x037E 0x0020 SWGR 2 FAIL TO OPEN F001 R 1
... ... ... ... ... ... ... ...
0x037F 0x0008 SWGR 16 FAIL TO OPEN F001 R 1
0x037F 0x0010 SWGR 1 FAIL TO CLOSE F001 R 1
0x037F 0x0020 SWGR 2 FAIL TO CLOSE F001 R 1
... ... ... ... ... ... ... ...
0x0380 0x0008 SWGR 16 FAIL TO CLOSE F001 R 1
0x0380 0x0010 SWGR 1 BLOCK OPENING F001 R 1
0x0380 0x0020 SWGR 2 BLOCK OPENING F001 R 1
0x0380 0x0040 SWGR 3 BLOCK OPENING F001 R 1
0x0380 0x0080 SWGR 4 BLOCK OPENING F001 R 1
0x0381 0x0100 SWGR 5 BLOCK OPENING F001 R 1
0x0381 0x0200 SWGR 6 BLOCK OPENING F001 R 1
0x0381 0x0400 SWGR 7 BLOCK OPENING F001 R 1
0x0381 0x0800 SWGR 8 BLOCK OPENING F001 R 1
0x0381 0x1000 SWGR 9 BLOCK OPENING F001 R 1
0x0381 0x2000 SWGR 10 BLOCK OPENING F001 R 1
0x0381 0x4000 SWGR 11 BLOCK OPENING F001 R 1
0x0381 0x8000 SWGR 12 BLOCK OPENING F001 R 1
0x0381 0x0001 SWGR 13 BLOCK OPENING F001 R 1
0x0381 0x0002 SWGR 14 BLOCK OPENING F001 R 1
0x0381 0x0004 SWGR 15 BLOCK OPENING F001 R 1
0x0381 0x0008 SWGR 16 BLOCK OPENING F001 R 1
0x0381 0x0010 SWGR 1 BLOCK CLOSING F001 R 1
0x0381 0x0020 SWGR 2 BLOCK CLOSING F001 R 1
0x0381 0x0040 SWGR 3 BLOCK CLOSING F001 R 1
0x0381 0x0080 SWGR 4 BLOCK CLOSING F001 R 1
0x0382 0x0100 SWGR 5 BLOCK CLOSING F001 R 1
0x0382 0x0200 SWGR 6 BLOCK CLOSING F001 R 1
0x0382 0x0400 SWGR 7 BLOCK CLOSING F001 R 1
0x0382 0x0800 SWGR 8 BLOCK CLOSING F001 R 1
0x0382 0x1000 SWGR 9 BLOCK CLOSING F001 R 1
0x0382 0x2000 SWGR 10 BLOCK CLOSING F001 R 1
0x0382 0x4000 SWGR 11 BLOCK CLOSING F001 R 1
0x0382 0x8000 SWGR 12 BLOCK CLOSING F001 R 1
0x0382 0x0001 SWGR 13 BLOCK CLOSING F001 R 1
0x0382 0x0002 SWGR 14 BLOCK CLOSING F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
