B-44 F650 DIGITAL BAY CONTROLLER GEK-106310-AF

B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL

Estados Función 32N (Nivel Alto y Nivel Bajo) - wattmetric Ground Fault Status (High and Low Level)

0x0450 0x0080 32N1 HIGH BLOCK F001 R 1

0x0451 0x0100 32N1 HIGH PKP F001 R 1

0x0451 0x0200 32N1 HIGH OC PKP F001 R 1

0x0451 0x0400 32N1 HIGH OP F001 R 1

0x0452 0x0800 32N2 HIGH BLOCK F001 R 1

0x0452 0x1000 32N2 HIGH PKP F001 R 1

0x0452 0x2000 32N2 HIGH OC PKP F001 R 1

0x0452 0x4000 32N2 HIGH OP F001 R 1

0x0453 0x8000 32N3 HIGH BLOCK F001 R 1

0x0453 0x0001 32N3 HIGH PKP F001 R 1

0x0453 0x0002 32N3 HIGH OC PKP F001 R 1

0x0453 0x0004 32N3 HIGH OP F001 R 1

0x0454 0x0008 32N1 LOW BLOCK F001 R 1

0x0454 0x0010 32N1 LOW PKP F001 R 1

0x0454 0x0020 32N1 LOW OC PKP F001 R 1

0x0454 0x0040 32N1 LOW OP F001 R 1

0x0455 0x0080 32N2 LOW BLOCK F001 R 1

0x0456 0x0100 32N2 LOW PKP F001 R 1

0x0456 0x0200 32N2 LOW OC PKP F001 R 1

0x0456 0x0400 32N2 LOW OP F001 R 1

0x0457 0x0800 32N3 LOW BLOCK F001 R 1

0x0457 0x1000 32N3 LOW PKP F001 R 1

0x0457

0x2000 32N3 LOW OC PKP F001 R 1

0x0457 0x4000 32N3 LOW OP F001 R 1

Digital Counters actual values

0x04A4 0x0002 DIGCNT 1 BLOCK F001 R 1

0x04A4 0x0004 DIGCNT 2 BLOCK F001 R 1

0x04A4 0x0008 DIGCNT 3 BLOCK F001 R 1

0x04A4 0x0010 DIGCNT 4 BLOCK F001 R 1

0x04A4 0x0020 DIGCNT 5 BLOCK F001 R 1

0x04A4 0x0040 DIGCNT 6 BLOCK F001 R 1

0x04A4 0x0080 DIGCNT 7 BLOCK F001 R 1

0x04A5 0x0100 DIGCNT 8 BLOCK F001 R 1

0x04A5 0x0200 DIGCNT 1 HI F001 R 1

0x04A5 0x0400 DIGCNT 2 HI F001 R 1

0x04A5 0x0800 DIGCNT 3 HI F001 R 1

0x04A5 0x1000 DIGCNT 4 HI F001 R 1

0x04A5 0x2000 DIGCNT 5 HI F001 R 1

0x04A5 0x4000 DIGCNT 6 HI F001 R 1

0x04A5 0x8000 DIGCNT 7 HI F001 R 1

0x04A5 0x0001 DIGCNT 8 HI F001 R 1

0x04A5 0x0002 DIGCNT 1 EQ F001 R 1

0x04A5 0x0004 DIGCNT 2 EQ F001 R 1

0x04A5 0x0008 DIGCNT 3 EQ F001 R 1

0x04A5 0x0010 DIGCNT 4 EQ F001 R 1

0x04A5 0x0020 DIGCNT 5 EQ F001 R 1

0x04A5 0x0040 DIGCNT 6 EQ F001 R 1

0x04A5

0x0080 DIGCNT 7 EQ F001 R 1

0x04A6 0x0100 DIGCNT 8 EQ F001 R 1

ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
