APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP

GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-45

0x04A6 0x0200 DIGCNT 1 LO F001 R 1

0x04A6 0x0400 DIGCNT 2 LO F001 R 1

0x04A6 0x0800 DIGCNT 3 LO F001 R 1

0x04A6 0x1000 DIGCNT 4 LO F001 R 1

0x04A6 0x2000 DIGCNT 5 LO F001 R 1

0x04A6 0x4000 DIGCNT 6 LO F001 R 1

0x04A6 0x8000 DIGCNT 7 LO F001 R 1

0x04A6 0x0001 DIGCNT 8 LO F001 R 1

0x04A6 0x0002 DIGCNT 1 UP F001 R 1

0x04A6 0x0004 DIGCNT 2 UP F001 R 1

0x04A6 0x0008 DIGCNT 3 UP F001 R 1

0x04A6 0x0010 DIGCNT 4 UP F001 R 1

0x04A6 0x0020 DIGCNT 5 UP F001 R 1

0x04A6 0x0040 DIGCNT 6 UP F001 R 1

0x04A6 0x0080 DIGCNT 7 UP F001 R 1

0x04A7 0x0100 DIGCNT 8 UP F001 R 1

0x04A7 0x0200 DIGCNT 1 DOWN F001 R 1

0x04A7 0x0400 DIGCNT 2 DOWN F001 R 1

0x04A7 0x0800 DIGCNT 3 DOWN F001 R 1

0x04A7 0x1000 DIGCNT 4 DOWN F001 R 1

0x04A7 0x2000 DIGCNT 5 DOWN F001 R 1

0x04A7 0x4000 DIGCNT 6 DOWN F001 R 1

0x04A7

0x8000 DIGCNT 7 DOWN F001 R 1

0x04A7 0x0001 DIGCNT 8 DOWN F001 R 1

0x04A7 0x0002 DIGCNT 1 SETPRESET F001 R 1

0x04A7 0x0004 DIGCNT 2 SETPRESET F001 R 1

0x04A7 0x0008 DIGCNT 3 SETPRESET F001 R 1

0x04A7 0x0010 DIGCNT 4 SETPRESET F001 R 1

0x04A7 0x0020 DIGCNT 5 SETPRESET F001 R 1

0x04A7 0x0040 DIGCNT 6 SETPRESET F001 R 1

0x04A7 0x0080 DIGCNT 7 SETPRESET F001 R 1

0x04A8 0x0100 DIGCNT 8 SETPRESET F001 R 1

0x04A8 0x0200 DIGCNT 1 RESET F001 R 1

0x04A8 0x0400 DIGCNT 2 RESET F001 R 1

0x04A8 0x0800 DIGCNT 3 RESET F001 R 1

0x04A8 0x1000 DIGCNT 4 RESET F001 R 1

0x04A8 0x2000 DIGCNT 5 RESET F001 R 1

0x04A8 0x4000 DIGCNT 6 RESET F001 R 1

0x04A8 0x8000 DIGCNT 7 RESET F001 R 1

0x04A8 0x0001 DIGCNT 8 RESET F001 R 1

0x04A8 0x0002 DIGCNT 1 FREEZERESET F001 R 1

0x04A8 0x0004 DIGCNT 2 FREEZERESET F001 R 1

0x04A8 0x0008 DIGCNT 3 FREEZERESET F001 R 1

0x04A8 0x0010 DIGCNT 4 FREEZERESET F001 R 1

0x04A8 0x0020 DIGCNT 5 FREEZERESET

F001 R 1

0x04A8 0x0040 DIGCNT 6 FREEZERESET F001 R 1

0x04A8 0x0080 DIGCNT 7 FREEZERESET F001 R 1

0x04A9 0x0100 DIGCNT 8 FREEZERESET F001 R 1

0x04A9 0x0200 DIGCNT 1 FREEZECOUNT F001 R 1

ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
