B-46 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x04A9 0x0400 DIGCNT 2 FREEZECOUNT F001 R 1
0x04A9 0x0800 DIGCNT 3 FREEZECOUNT F001 R 1
0x04A9 0x1000 DIGCNT 4 FREEZECOUNT F001 R 1
0x04A9 0x2000 DIGCNT 5 FREEZECOUNT F001 R 1
0x04A9 0x4000 DIGCNT 6 FREEZECOUNT F001 R 1
0x04A9 0x8000 DIGCNT 7 FREEZECOUNT F001 R 1
0x04A9 0x0001 DIGCNT 8 FREEZECOUNT F001 R 1
Cold Load Pick up actual values
0x04D8 0x0002 Cold Load PKP F001 R 1
0x04D8 0x0004 Cold Load OP F001 R 1
0x04D8 0x0008 Cold Load BLOCK F001 R 1
Entradas Analógicas (Tarjetas F y G)- Analog Inputs (F and G boards)(Do not apply to C650 models)
0x0B06 ANALOG_INP_F_01 F002 1000 R 2
0x0B08 ANALOG_INP_F_02 F002 1000 R 2
... ... ... ... ... ... ...
0x0B14 ANALOG_INP_F_08 F002 1000 R 2
0x0B86 ANALOG_INP_G_01 F002 1000 R 2
0x0B88 ANALOG_INP_G_02 F002 1000 R 2
... ... ... ... ... ... ...
0x0B94 ANALOG_INP_G_08 F002 1000 R 2
Medidas en Valores Secundarios - Analog measures in Secondary Values
0x0C00 Phasor Ia F002 1000 R 2
0x0C02 RMS Ia F002 1000 R 2
0x0C04 Ia Real F002 1000 R 2
0x0C06 Ia Imag F002 1000 R 2
0x0C08 Phasor Ib F002 1000 R 2
0x0C0A RMS Ib F002 1000 R 2
0x0C0C Ib Real F002 1000 R 2
0x0C0E Ib Imag F002 1000 R 2
0x0C10 Phasor Ic F002 1000 R 2
0x0C12 RMS Ic F002 1000 R 2
0x0C14 Ic Real F002 1000 R 2
0x0C16 Ic Imag F002 1000 R 2
0x0C18 Phasor In F002 1000 R 2
0x0C1A In Real F002 1000 R 2
0x0C1C In Imag F002 1000 R 2
0x0C1E Phasor Ig F002 1000 R 2
0x0C20 RMS Ig F002 1000
R 2
0x0C22 Ig Real F002 1000 R 2
0x0C24 Ig Imag F002 1000 R 2
0x0C26 Phasor Isg F002 1000 R 2
0x0C28 RMS Isg F002 1000 R 2
0x0C2A Isg Real F002 1000 R 2
0x0C2C Isg Imag F002 1000 R 2
0x0C2E Zero seq I0 F002 1000 R 2
0x0C30 I0 Real F002 1000 R 2
0x0C32 I0 Imag F002 1000 R 2
0x0C34 Positive Seq I1 F002 1000 R 2
0x0C36 I1 Real F002 1000 R 2
0x0C38 I1 Imag F002 1000 R 2
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
