APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-47
0x0C3A Negative Seq I2 F002 1000 R 2
0x0C3C I2 Real F002 1000 R 2
0x0C3E I2 Imag F002 1000 R 2
0x0C40 Phasor Vab F002 1000 R 2
0x0C42 Vab Real F002 1000 R 2
0x0C44 Vab Imag F002 1000 R 2
0x0C46 Phasor Vbc F002 1000 R 2
0x0C48 Vbc Real F002 1000 R 2
0x0C4A Vbc Imag F002 1000 R 2
0x0C4C Phasor Vca F002 1000 R 2
0x0C4E Vca Real F002 1000 R 2
0x0C50 Vca Imag F002 1000 R 2
0x0C52 Phasor Van F002 1000 R 2
0x0C54 Va Real F002 1000 R 2
0x0C56 Va Imag F002 1000 R 2
0x0C58 Phasor Vbn F002 1000 R 2
0x0C5A Vb Real F002 1000
R 2
0x0C5C Vb Imag F002 1000 R 2
0x0C5E Phasor Vcn F002 1000 R 2
0x0C60 Vc Real F002 1000 R 2
0x0C62 Vc Imag F002 1000 R 2
0x0C64 Phasor Vn F002 1000 R 2
0x0C66 Vn Real F002 1000 R 2
0x0C68 Vn Imag F002 1000 R 2
0x0C6A Positive Seq V1 F002 1000 R 2
0x0C6C V1 Real F002 1000 R 2
0x0C6E V1 Imag F002 1000 R 2
0x0C70 Negative Seq V2 F002 1000 R 2
0x0C72 V2 Real F002 1000 R 2
0x0C74 V2 Imag F002 1000 R 2
0x0C76 Zero Seq V0 F002 1000 R 2
0x0C78 V0 Real F002 1000 R 2
0x0C7A V0 Imag F002 1000 R 2
0x0C7C Phasor Vx
F002 1000 R 2
0x0C7E Vx Real F002 1000 R 2
0x0C80 Vx Imag F002 1000 R 2
0x0C82 Nominal Voltage F002 1000 R 2
0x0C84 VL Real F002 1000 R 2
0x0C86 VL Imag F002 1000 R 2
0x0C88 VBB Real F002 1000 R 2
0x0C8A VBB Imag F002 1000 R 2
0x0C8C Line Voltage F002 1000 R 2
0x0C8E Bus Voltage F002 1000 R 2
0x0C90 Line Frequency F002 1000 R 2
0x0C92 Bus Frequency F002 1000 R 2
0x0C94 Phase A Apparent Pwr F002 1000 R 2
0x0C96 Phase B Apparent Pwr F002 1000 R 2
0x0C98 Phase C Apparent Pwr F002 1000 R 2
0x0C9A Phase A Real Pwr F002 1000 R 2
0x0C9C Phase B Real Pwr F002 1000 R 2
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
