B-48 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x0C9E Phase C Real Pwr F002 1000 R 2
0x0CA0 Phase A Reactive Pwr F002 1000 R 2
0x0CA2 Phase B Reactive Pwr F002 1000 R 2
0x0CA4 Phase C Reactive Pwr F002 1000 R 2
0x0CA6 3 Phase Apparent Pwr F002 1000 R 2
0x0CA8 3 Phase Real Pwr F002 1000 R 2
0x0CAA 3 Phase Reactive Pwr F002 1000 R 2
0x0CAC Phase A Power Factor F002 1000 R 2
0x0CAE Phase B Power Factor F002 1000 R 2
0x0CB0 Phase C Power Factor F002 1000 R 2
0x0CB2 3 Phase Power Factor F002 1000 R 2
Ratios corriente y tensión - Current and Voltage Ratios
0x0CB4 CT Ratio F002 1000 R 2
0x0CB6 CT Ratio Ig F002 1000 R 2
0x0CB8 CT Ratio Isg F002 1000 R 2
0x0CBA PT Ratio F002 1000 R 2
Angulos - Angles
0x0CBC Ia Angle F002 1000 R 2
0x0CBE Ib Angle F002 1000 R 2
0x0CC0 Ic Angle F002 1000 R 2
0x0CC2 In Angle F002 1000 R 2
0x0CC4 Ig Angle F002 1000 R 2
0x0CC6 Isg Angle F002 1000 R 2
0x0CC8 Va Angle F002 1000 R 2
0x0CCA Vb Angle F002 1000 R 2
0x0CCC Vc Angle F002 1000 R 2
0x0CCE Vn Angle F002 1000 R 2
0x0CD0 Vx Angle F002 1000 R 2
0x0CD2 Vab Angle F002 1000 R 2
0x0CD4 Vbc Angle F002 1000 R 2
0x0CD6 Vca Angle F002 1000 R 2
Frequency rate of change value
0x0CD8 df/dt F002 1000
0
R 2
Versión del HMI - HMI Version
0x0CE2 HMI Version F004 1000 R 1
0x0CE3 DISPLAY TYPE F004 1000 R 1
0x0CE4 PreFault Ia Mod F002 1000
000
R 2
0x0CE6 PreFault Ia Ang F003 1000 R 2
0x0CE8 PreFault Ib Mod F002 1000
00
0
R 2
0x0CEA PreFault Ib Ang F003 1000 R 2
0x0CEC PreFault Ic Mod F002 1000
00
0
R 2
0x0CEE PreFault Ic Ang F003 1000 R 2
0x0CF0 PreFault Vab Mod F002 1000
00
0
R 2
0x0CF2 PreFault Vab Ang F003 1000 R 2
0x0CF4 PreFault Vbc Mod F002 1000
00
0
R 2
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
