APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-49
0x0CF6 PreFault Vbc Ang F003 1000 R 2
0x0CF8 PreFault Vca Mod F002 1000
00
0
R 2
0x0CFA PreFault Vca Ang F003 1000 R 2
0x0CFC PreFault Ig Mod F002 1000
00
0
R 2
0x0CFE PreFault Ig Ang F003 1000 R 2
0x0D00 PreFault Isg Mod F002 1000
00
0
R 2
0x0D02 PreFault Isg Ang F003 1000 R 2
0x0D04 PostFault Ia Mod F002 1000
00
0
R 2
0x0D06 PostFault Ia Ang F003 1000 R 2
0x0D08 PostFault Ib Mod F002 1000
00
0
R 2
0x0D0A PostFault Ib Ang F003 1000 R 2
0x0D0C PostFault Ic Mod F002 1000
00
0
R 2
0x0D0E PostFault Ic Ang F003 1000 R 2
0x0D10 PostFault Vab Mod F002 1000
00
0
R 2
0x0D12 PostFault Vab Ang F003 1000 R 2
0x0D14 PostFault Vbc Mod F002 1000
00
0
R 2
0x0D16 PostFault Vbc Ang F003 1000 R 2
0x0D18 PostFault Vca Mod F002 1000
00
0
R 2
0x0D1A PostFault Vca Ang F003 1000 R 2
0x0D1C PostFault Ig Mod F002 1000
00
0
R 2
0x0D1E PostFault Ig Ang F003 1000 R 2
0x0D20 PostFault Isg Mod F002 1000
00
0
R 2
0x0D22
PostFault Isg Ang F003 1000 R 2
Valores Imagen Térmica - Thermal Image Values
0x0DD9 THERMAL1 IMAGE A F003 1 R 2
0x0DDB THERMAL1 IMAGE B F003 1 R 2
0x0DDD THERMAL1 IMAGE C F003 1 R 2
0x0DE4 THERMAL2 IMAGE A F003 1 R 2
0x0DE6 THERMAL2 IMAGE B F003 1 R 2
0x0DE8 THERMAL2 IMAGE C F003 1 R 2
0x0DEF THERMAL3 IMAGE A F003 1 R 2
0x0DF1 THERMAL3 IMAGE B F003 1 R 2
0x0DF3 THERMAL3 IMAGE C F003 1 R 2
Diferencia de tensión para la función de sincronismo-Voltage Difference for synchrocheck unit
0x0E31 VOLTAGE DIFFERENCE F002 1000
0
R 2
Diferencia de Frecuencia para la función de sincronismo-Frequency Difference for synchrocheck unit
0x0E33 FREQ. DIFFERENCE F002 1000
0
R 2
Estados Reenganchador (Enumerado) - Autorecloser Status
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
