B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x0E36 AR STATUS F012 R 1 0=OUT OF SERVICE
1=READY
2=LOCKOUT
3=BLOCK
4=RECLOSE IN PROGRESS
0x0E37 AR LOCKOUT MODE F012 R 1 0=NONE
1=ANOMALY
2=FAIL TO OPEN
3=FAIL TO CLOSE
4=MANUAL
5=NO CONDITIONS
6=MAX NUMBER OF TRIPS
7=LAST SHOT
0x0E38 AR BLOCK MODE F012 R 1 0=NONE
1=LEVEL
2=PULSE
3=LEVEL+PULSE
Estados Oscilografía - Oscillography States
0x0EB6 NUMBER OF TRIGGERS F004 1 R 1
0x0EB7 CYCLES PER RECORD F004 1 R 1
0x0EB8 AVAILABLE RECORDS F004 1 R 1
Estados Localizador de Faltas - Fault Report States
0x0EBB FAULT DATE F011 R 3
0x0EBE FAULT TYPE F012 R 1 0=GROUND
1=PHASE
2=3 PH
3=AG
4=ABG
5=AB
6=BG
7=BCG
8=BC
9=CG
10=CAG
11=CA
12=NAF
0x0EBF FAULT LOCATION F003 1 R 2
0x0EC1 FAULT REPORT NUMBER F005 1 R 2
0x0EC3 R Primary F003 1000 R 2
0x0EC5 R Secondary F003 1000 R 2
0x0EC7 X Primary F003 1000 R 2
0x0EC9 X Secondary F003 1000 R 2
0x0ECB FAULT RESISTANCE F003 R 2
Medidas en Valores Primarios - Analog measures in Primary Values
0x0EE2 Phasor Ia Primary F002 1000 R 2
0x0EE4 Phasor Ib Primary F002 1000 R 2
0x0EE6 Phasor Ic Primary F002 1000 R 2
0x0EE8 Phasor Ig Primary F002 1000 R 2
0x0EEA Phasor Isg Primary F002 1000 R 2
0x0EEC Phasor In Primary F002 1000 R 2
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
