APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-51
0x0EEE RMS Ia Primary F002 1000 R 2
0x0EF0 RMS Ib Primary F002 1000 R 2
0x0EF2 RMS Ic Primary F002 1000 R 2
0x0EF4 RMS Ig Primary F002 1000 R 2
0x0EF6 RMS Isg Primary F002 1000 R 2
0x0EF8 I0 Primary F002 1000 R 2
0x0EFA I1 Primary F002 1000 R 2
0x0EFC I2 Primary F002 1000 R 2
0x0EFE V0 Primary F002 1000 R 2
0x0F00 V1 Primary F002 1000 R 2
0x0F02 V2 Primary F002 1000 R 2
0x0F04 Vab Primary F002 1000 R 2
0x0F06 Vbc Primary F002 1000 R 2
0x0F08 Vca Primary F002 1000 R 2
0x0F0A Va Primary F002 1000 R 2
0x0F0C Vb Primary F002 1000 R 2
0x0F0E Vc Primary F002 1000
R 2
0x0F10 Vn Primary F002 1000 R 2
0x0F12 Vx Primary F002 1000 R 2
0x0F14 VBB Primary F002 1000 R 2
0x0F16 VL Primary F002 1000 R 2
0x0F18 Phase A Real Pwr F002 1000 R 2
0x0F1A Phase A Reactive Pwr F002 1000 R 2
Medidas en Valores Primarios - Analog measures in Primary Values(cont.)
0x0F1C Phase A Apparent Pwr F002 1000 R 2
0x0F1E Phase B Real Pwr F002 1000 R 2
0x0F20 Phase B Reactive Pwr F002 1000 R 2
0x0F22 Phase B Apparent Pwr F002 1000 R 2
0x0F24 Phase C Real Pwr F002 1000 R 2
0x0F26 Phase C Reactive Pwr F002 1000 R 2
0x0F28 Phase C Apparent Pwr F002 1000 R 2
0x0F2A 3 Phase Real Pwr F002 1000 R 2
0x0F2C 3 Phase Reactive Pwr F002 1000 R 2
0x0F2E 3 Phase Apparent Pwr F002 1000 R 2
0x0F30 Phase A Power Factor F002 1000 R 2
0x0F32 Phase B Power Factor F002 1000 R 2
0x0F34 Phase C Power Factor F002 1000 R 2
0x0F36 3 Phase Power Factor F002 1000 R 2
0x0F38 Line Frequency F002 1000 R 2
0x0F3A Bus Frequency F002 1000 R 2
0x0F3C Positive MWatthour F002 1000
R 2
0x0F3E Negative MWatthour F002 1000 R 2
0x0F40 Positive MVarhour F002 1000 R 2
0x0F42 Negative MVarhour F002 1000 R 2
0x0F44 Pos MWatthour Cnt F002 1000 R 2
0x0F46 Neg MWatthour Cnt F002 1000 R 2
0x0F48 Pos MVarhour Cnt F002 1000 R 2
0x0F4A Neg MVarhour Cnt F002 1000 R 2
0x0F4C % of Load-To-Trip F002 1000 R 2
Medidas Demanda - Demand measures
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
