B-52 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x0FAB DEMAND IA F002 1000 R 2
0x0FAD DEMAND IA MAX F002 1000 R 2
0x0FAF DEMAND IA DATE F011 R 3
0x0FB2 DEMAND IB F002 1000 R 2
0x0FB4 DEMAND IB MAX F002 1000 R 2
0x0FB6 DEMAND IB DATE F011 R 3
0x0FB9 DEMAND IC F002 1000 R 2
0x0FBB DEMAND IC MAX F002 1000 R 2
0x0FBD DEMAND IC DATE F011 R 3
0x0FC0 DEMAND IG F002 1000 R 2
0x0FC2 DEMAND IG MAX F002 1000 R 2
0x0FC4 DEMAND IG DATE F011 R 3
0x0FC7 DEMAND ISG F002 1000 R 2
0x0FC9 DEMAND ISG MAX F002 1000 R 2
0x0FCB DEMAND ISG DATE F011 R 3
0x0FCE DEMAND I2 F002 1000 R 2
0x0FD0 DEMAND I2 MAX F002 1000
R 2
0x0FD2 DEMAND I2 DATE F011 R 3
0x0FD5 DEMAND W F002 1000 R 2
0x0FD7 DEMAND W MAX F002 1000 R 2
0x0FD9 DEMAND W DATE F011 R 3
0x0FDC DEMAND VAR PWR F002 1000 R 2
0x0FDE DEMAND VAR MAX F002 1000 R 2
0x0FE0 DEMAND VAR DATE F011 R 3
0x0FE3 DEMAND VA PWR F002 1000 R 2
0x0FE5 DEMAND VA MAX F002 1000 R 2
0x0FE7 DEMAND VA DATE F011 R 3
Entradas Analógicas (Tarjetas J y H)- Analog Inputs (J and H boards)
0x0FFE ANALOG_INP_H_01 F002 1000 R 2
0x1000 ANALOG_INP_H_02 F002 1000 R 2
... ... ... ... ... ... ...
0x100C ANALOG_INP_H_08 F002 1000 R 2
0x107E ANALOG_INP_J_01 F002 1000 R 2
0x1080 ANALOG_INP_J_02 F002 1000 R 2
... ... ... ... ... ... ...
0x108C ANALOG_INP_J_08 F002 1000 R 2
Contadores de Interruptor - Breaker Counters
0x111D BREAKER OPENINGS F005 1 R 2
0x111F BREAKER CLOSINGS F005 1 R 2
0x1121 KI2t PHASE A F003 1 R 2
0x1123 KI2t PHASE B F003 1 R 2
0x1125 KI2t PHASE C F003 1 R 2
0x1127 BKR OPENING TIME F003 1 R 2
0x1129 BKR CLOSING TIME F003 1 R 2
0x112B BKR OPEN TIMING F003 1 R 2
0x112D BKR CLOSE TIMING F003 1 R 2
Registrador de Datos - Data Logger
0x1153 OLDEST SAMPLE TIME F011 R 3
0x1156 NEWEST SAMPLE TIME F011 R 3
0x1159 DATA LOGGER CHANNELS F004 1 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
