APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-53
0x115A DATA LOGGER DAYS F003 1 R 2
Estados Internos Sistema - Internal System States
0x1160 Kswapd Time ** F005 1 R 2
0x1162 mtd2 Time ** F005 1 R 2
0x1164 mtd3 Time ** F005 1 R 2
0x1166 CPU Rtai ** F005 1 R 2
0x1168 CPU Linux ** F005 1 R 2
0x116A Total RAM F005 1024 R 2
0x116C Used DRAM F005 1024 R 2
0x116E Free RAM ** F005 1024 R 2
0x1170 Shared RAM ** F005 1024 R 2
0x1172 Buffer RAM ** F005 1024 R 2
0x1174 Cached RAM ** F005 1024 R 2
0x1176 Green Counter ** F005 1 R 2
0x1178 Yellow Counter ** F005 1 R 2
0x117A Orange Counter ** F005 1 R 2
0x117C Red Counter ** F005 1 R 2
0x117E UpTime F005 1 R 2
0x1180 DSP Counter F005 1000 R
2
0x1182 CPU Usage F004 1000 R
1
0x120E ICD STATUS F012 R 1 0=UNKNOWN
1=ICD ERROR
2=MODIFIED
3=IN PROGRESS
4=OK WITHOUT DAIS
5=OK
6=NotValidated Empty
7=Passed to Validated
8=Default
9=ERROR HEADER CID
10=ERROR SG CID
0x120F ICD STATUS NOTVAL F012 R 1 0=UNKNOWN
1=ICD ERROR
2=MODIFIED
3=IN PROGRESS
4=OK WITHOUT DAIS
5=OK
6=NotValidated Empty
7=Passed to Validated
8=Default
9=ERROR HEADER CID
10=ERROR SG CID
** For version previous to 7.00
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
