B-54 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
Valor del Contador de Pulsos-Pulse Counter Value
0x121B PulseCntr Value 1 F002 1000
000
R 2
0x121D PulseCntr Value 2 F002 1000
000
R 2
0x121F PulseCntr Value 3 F002 1000
000
R 2
0x1221 PulseCntr Value 4 F002 1000
000
R 2
0x1223 PulseCntr Value 5 F002 1000
000
R 2
0x1225 PulseCntr Value 6 F002 1000
000
R 2
0x1227 PulseCntr Value 7 F002 1000
000
R 2
0x1229 PulseCntr Value 8 F002 1000
000
R 2
Valor del Contador de Pulsos Congelado-Freeze Pulse Counter Value
0x122B PulseCntr Freeze 1 F002 1000
000
R 2
0x122D PulseCntr Freeze 2 F002 1000
000
R 2
0x122F PulseCntr Freeze 3 F002 1000
000
R 2
0x1231 PulseCntr Freeze 4 F002 1000
000
R 2
0x1233 PulseCntr Freeze 5 F002 1000
000
R 2
0x1235 PulseCntr Freeze 6 F002 1000
000
R 2
0x1237 PulseCntr Freeze 7 F002 1000
000
R 2
0x1239 PulseCntr Freeze 8 F002 1000
000
R 2
0x1263 GLOBAL STARTS CNT F005 1000 R 2
0x1265 BLOCK LOCKOUT TIME F005 1000 R 2
Entradas analógicas remotas tipo float- Float Remote Analog Input
0x126D Rem Ana Inp FLOAT 1 F003 1000 R 2
0x126F Rem Ana Inp FLOAT 2 F003 1000 R 2
0x1271 Rem Ana Inp FLOAT 3 F003 1000 R 2
0x1273 Rem Ana Inp FLOAT 4 F003 1000 R 2
0x1275 Rem Ana Inp FLOAT 5 F003 1000 R 2
0x1277 Rem Ana Inp FLOAT 6 F003 1000 R 2
0x1279 Rem Ana Inp FLOAT 7 F003 1000 R 2
0x127B Rem Ana Inp FLOAT 8 F003 1000 R 2
Entradas analogicas remotas tipo entero- Integer Remote Analog Input
0x127D Rem Ana Inp INT 1 F005 1000 R 2
0x127F Rem Ana Inp INT 2 F005 1000 R 2
0x1281 Rem Ana Inp INT 3 F005 1000 R 2
0x1283 Rem Ana Inp INT 4 F005 1000 R 2
0x1285 Rem Ana Inp INT 5 F005 1000 R 2
0x1287 Rem Ana Inp INT 6 F005 1000 R 2
0x1289 Rem Ana Inp INT 7 F005 1000 R 2
0x128B Rem Ana Inp INT 8 F005 1000 R 2
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
