APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-55
Medidas Potencia Función 32N (Nivel Alto y Bajo) - wattmetric Ground Fault Power Measurements (High and Low Level)
0x1349 32N1 HIGH POWER F002 1000 R 2
0x1350 32N2 HIGH POWER F002 1000 R 2
0x1357 32N3 HIGH POWER F002 1000 R 2
0x135E 32N1 LOW POWER F002 1000 R 2
0x1365 32N2 LOW POWER F002 1000 R 2
0x136C 32N3 LOW POWER F002 1000 R 2
Digital Counters Status
0x147D DIGCNT 1 VALUE F005 1000 R 2
0x147F DIGCNT 2 VALUE F005 1000 R 2
0x1481 DIGCNT 3 VALUE F005 1000 R 2
0x1483 DIGCNT 4 VALUE F005 1000 R 2
0x1485 DIGCNT 5 VALUE F005 1000 R 2
0x1487 DIGCNT 6 VALUE F005 1000 R 2
0x1489 DIGCNT 7 VALUE F005 1000 R 2
0x148B DIGCNT 8 VALUE F005 1000 R 2
0x148D DIGCNT 1 FROZENVALUE F005 1000 R 2
0x148F DIGCNT 2 FROZENVALUE F005 1000 R 2
0x1491 DIGCNT 3 FROZENVALUE F005 1000 R 2
0x1493 DIGCNT 4 FROZENVALUE F005 1000 R 2
0x1495 DIGCNT 5 FROZENVALUE F005 1000 R 2
0x1497 DIGCNT 6 FROZENVALUE F005 1000 R 2
0x1499 DIGCNT 7 FROZENVALUE F005 1000 R 2
0x149B DIGCNT 8 FROZENVALUE F005 1000 R 2
0x149D DIGCNT 1 FROZENDATE F011 R 3
0x14A0 DIGCNT 2 FROZENDATE F011 R 3
0x14A3 DIGCNT 3 FROZENDATE F011 R 3
0x14A6 DIGCNT 4 FROZENDATE F011 R 3
0x14A9 DIGCNT 5 FROZENDATE F011 R 3
0x14AC DIGCNT 6 FROZENDATE F011 R 3
0x14AF DIGCNT 7 FROZENDATE F011 R 3
0x14B2 DIGCNT 8 FROZENDATE
F011 R 3
PTP 1588 Status
0x14E5 RTC Sync Source F012 1000 R 1 0=INTERNAL
1=PTP-PORT
2=SNTP
3=IRIG-B
4=SNTP2
0x14E6 GrandMaster-ID LOW F009 1000 R 4
0x14EA GrandMaster-ID HIGH F009 1000 R 4
0x14EE PTP ACCURACY F005 1000 R 2
0x14F0 PTP PORT A STATE F012 1000 R 1 0=DISABLED
1=NO SIGNAL
2=CALIBRATING
3=SYNCHD_NO_PDELAY
4=SYNCHRONIZED
0x14F1 PTP PORT B STATE F012 1000 R 1 0=DISABLED
1=NO SIGNAL
2=CALIBRATING
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
