B-56 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
3=SYNCHD_NO_PDELAY
4=SYNCHRONIZED
Application Versions (Part II)
0x14F3 Boot Version F004 1000 R 1
0x14F4 Boot Date F009 R 10
0x14FE Kinetis Boot Version F004 1000 R 1
0x14FF Kinetis Boot Date F009 R 10
0x1509 Kinetis Loader Ver F004 1000 R 1
0x150A Kinetis Loader Date F009 R 10
0x1514 Kinetis App Version F004 1000 R 1
0x1515 Kinetis App Date F009 R 10
0x151F DSP Version F004 1000 R 1
0x1520 DSP Date F009 R 16
Internal System States (Part II)
0x1530 DSP Status F005 1000 R 2
Application Versions (Part III)
0x1535 Firmware Date F009 R 10
0x153F FPGA Version F009 1000 R 4
Internal System States (Part III)
0x1543 FLASH Usage F004 1000 R 1
0x1544 KINETIS Status F012 R 1 0=ERROR
1=BOOT_MODE
2=APP_MODE
0x1545 CPU MAX Usage F004 1000 R 1
Application Versions (Part IV)
0x1546 RM PRP HSR Version F009 1000 R 4
0x154A RM RSTP Version F009 1000 R 4
0x154E RM LLA Version F009 1000 R 4
0x1552 RM Bypass Version F009 1000 R 4
Internal System States (Part IV)
0x1556 Temp Current Value F004 1000 R 1
0x1557 Temp Max Value F004 1000 R 1
0x1558 Temp Min Value F004 1000 R 1
0x1559 Scan Cycle Average F004 1000 R 1
0x155A Scan Cycle Rate F004 1000 R 1
0x155C PLC Checksum F005 1000 R 2
0x155E Settings Checksum F005 1000 R 2
Application Versions (Part V)
0x1560 CPU Revision F004 1000 R 1
Redundancy status
0x157C PRP_HSR A tx F005 1000 R 2
0x157E PRP_HSR B tx F005 1000 R 2
0x1580 PRP_HSR A err F005 1000 R 2
0x1582 PRP_HSR B err F005 1000 R 2
0x1584 RSTP PortA State F012 R 1 0=DISCARDING
1=LEARNING
2=FORWARDING
0x1585 RSTP PortB State F012 R 1 0=DISCARDING
1=LEARNING
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
