APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-57
2=FORWARDING
Mapa de Usuario - User Map
0xF330 Address 00 F004 1 R 1
0xF331 Address 01 F004 1 R 1
... ... ... ... ... ... ... ...
0xF42F Address 255 F004 1 R 1
Textos Maniobras - Commands text
0x1C00 OPERATION 1 F009 1 R/W 16
0x1C10 OPERATION 2 F009 1 R/W 16
... ... ... ... ... ... ... ...
0x1DF0 OPERATION24 F009 1 R/W 16
0x1E00 Confirmation address W 1
PLC Timer Masks
0x1E01 TIMER MASK 01 F005 1 R/W 2 [0 , 86400000] ms
0x1E03 TIMER MASK 02 F005 1 R/W 2 [0 , 86400000] ms
0x1E05 TIMER MASK 03 F005 1 R/W 2 [0 , 86400000] ms
0x1E07 TIMER MASK 04 F005 1 R/W 2 [0 , 86400000] ms
0x1E09 TIMER MASK 05 F005 1 R/W 2 [0 , 86400000] ms
0x1E0B TIMER MASK 06 F005 1 R/W 2 [0 , 86400000] ms
0x1E0D TIMER MASK 07 F005 1 R/W 2 [0 , 86400000] ms
0x1E0F TIMER MASK 08 F005 1 R/W 2 [0 , 86400000] ms
0x1E11 TIMER MASK 09 F005 1 R/W 2 [0 , 86400000] ms
0x1E13 TIMER MASK 10 F005 1 R/W 2 [0 , 86400000] ms
0x1E15 TIMER MASK 11 F005 1 R/W 2 [0 , 86400000] ms
0x1E17 TIMER MASK 12 F005 1 R/W 2 [0 , 86400000] ms
0x1E19 TIMER MASK 13 F005 1 R/W 2 [0 , 86400000] ms
0x1E1B TIMER MASK 14 F005 1 R/W 2 [0 , 86400000] ms
0x1E1D TIMER MASK 15 F005 1 R/W 2 [0 , 86400000] ms
0x1E1F TIMER MASK 16 F005 1 R/W 2 [0 , 86400000] ms
0x1E3F Confirmation address W 1
Ajustes Tarjeta F - Board F Settings
Ajustes de Tensión Tarjeta F - Board F Voltage Settings
0x1E41 Voltage Threshold A_F F004 1 R/W 1 [10 , 230] V
0x1E42 Voltage Threshold B_F F004 1 R/W 1 [10 , 230] V
0x1EE6 Voltage Threshold C_F F004 1 R/W 1 [10 , 230] V
0x1EE7 Voltage Threshold D_F F004 1 R/W 1
[10 , 230] V
Ajustes Tiempo Antirrebotes Tarjeta F - Board F Debounce Time Settings
0x1E43 Debounce Time A_F F004 1 R/W 1 [1 , 50] ms
0x1E44 Debounce Time B_F F004 1 R/W 1 [1 , 50] ms
0x1EE8 Debounce Time C_F F004 1 R/W 1 [1 , 50] ms
0x1EE9 Debounce Time D_F F004 1 R/W 1
[1 , 50] ms
Ajuste Tipo de Entrada Tarjeta F (32 elementos) - Board F Input Type Setting (32 items)
0x1E45 Input Type_F_CC1 F012 1 R/W 1 0=POSITIVE-EDGE
1=NEGATIVE-EDGE
2=POSITIVE
3=NEGATIVE
0x1E46 Input Type_F_CC2 F012 1 R/W 1 0=POSITIVE-EDGE
1=NEGATIVE-EDGE
2=POSITIVE
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
