APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-59
4=0 to 5 mA
5=0 to 10 mA
6=0 to 20 mA
7=4 to 20 mA
... ... ... ... ... ... ... ...
0x1EF1 Range_F_08 F012 1 R/W 1 0=NONE
1=-1 to 0 mA
2=0 to 1 mA
3=-1 to 1 mA
4=0 to 5 mA
5=0 to 10 mA
6=0 to 20 mA
7=4 to 20 mA
Ajuste Rango de Medida de Entrada Analógica F (8 elementos) - Board F Analog Input Measurement Range (8 items)
0x1EF2 Min Value_F_01 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1EF4 Min Value_F_02 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1EF6 Min Value_F_03 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1EF8 Min Value_F_04 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1EFA Min Value_F_05 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1EFC Min Value_F_06 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1EFE Min Value_F_07 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F00 Min Value_F_08 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F02 Max Value_F_01 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F04 Max Value_F_02 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F06 Max Value_F_03 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F08 Max Value_F_04 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F0A Max Value_F_05 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F0C Max Value_F_06 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F0E Max Value_F_07 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F10 Max Value_F_08 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F12 Channelx1a_F_01 F003 1000 R/W 2 [0,950 , 1,050]
0x1F14 Channelx1a_F_02 F003 1000 R/W 2 [0,950 , 1,050]
0x1F16 Channelx1a_F_03 F003 1000 R/W 2 [0,950 , 1,050]
0x1F18 Channelx1a_F_04 F003 1000 R/W 2 [0,950 , 1,050]
0x1F1A Channelx1a_F_05 F003 1000 R/W 2 [0,950 , 1,050]
0x1F1C Channelx1a_F_06 F003 1000 R/W 2 [0,950 , 1,050]
0x1F1E Channelx1a_F_07 F003 1000 R/W 2 [0,950 , 1,050]
0x1F20 Channelx1a_F_08 F003 1000 R/W 2 [0,950 , 1,050]
0x1F22 Channelx1b_F_01 F004 1000 R/W 1 [-1000 , 1000]
0x1F23 Channelx1b_F_02 F004 1000 R/W 1 [-1000 , 1000]
0x1F24 Channelx1b_F_03 F004 1000 R/W 1 [-1000 , 1000]
0x1F25 Channelx1b_F_04 F004 1000 R/W 1 [-1000 , 1000]
0x1F26 Channelx1b_F_05 F004 1000 R/W 1 [-1000 , 1000]
0x1F27 Channelx1b_F_06 F004 1000 R/W 1 [-1000 , 1000]
0x1F28 Channelx1b_F_07 F004 1000 R/W 1 [-1000 , 1000]
0x1F29 Channelx1b_F_08 F004 1000 R/W 1 [-1000 , 1000]
0x1F2A Channelx10a_F_01 F003 1000 R/W 2 [0,950 , 1,050]
0x1F2C Channelx10a_F_02 F003 1000 R/W 2 [0,950 , 1,050]
0x1F2E Channelx10a_F_03 F003 1000 R/W 2 [0,950 , 1,050]
0x1F30 Channelx10a_F_04 F003 1000 R/W 2
[0,950 , 1,050]
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
