B-60 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x1F32 Channelx10a_F_05 F003 1000 R/W 2 [0,950 , 1,050]
0x1F34 Channelx10a_F_06 F003 1000 R/W 2 [0,950 , 1,050]
0x1F36 Channelx10a_F_07 F003 1000 R/W 2 [0,950 , 1,050]
0x1F38 Channelx10a_F_08 F003 1000 R/W 2 [0,950 , 1,050]
0x1F3A Channelx10b_F_01 F004 1000 R/W 1 [-1000 , 1000]
0x1F3B Channelx10b_F_02 F004 1000 R/W 1 [-1000 , 1000]
0x1F3C Channelx10b_F_03 F004 1000 R/W 1 [-1000 , 1000]
0x1F3D Channelx10b_F_04 F004 1000 R/W 1 [-1000 , 1000]
0x1F3E Channelx10b_F_05 F004 1000 R/W 1 [-1000 , 1000]
0x1F3F Channelx10b_F_06 F004 1000 R/W 1 [-1000 , 1000]
0x1F40 Channelx10b_F_07 F004 1000 R/W 1 [-1000 , 1000]
0x1F41 Channelx10b_F_08 F004 1000 R/W 1 [-1000 , 1000]
0x1F42 Calibration Type_F F012 1000 R/W 1 0=NONE
1=OFFSET
2=CALIBRATION
3=GET CALIBRATION
0x1FE4 Confirmation address W 1
Ajustes Tarjeta G - Board G Settings
Ajustes de Tensión Tarjeta G - Board G Voltage Settings
0x1FE6 Voltage Threshold A_G F004 1 R/W 1 [10 , 230] V
0x1FE7 Voltage Threshold B_G F004 1 R/W 1 [10 , 230] V
0x208B Voltage Threshold C_G F004 1 R/W 1 [10 , 230] V
0x208C Voltage Threshold D_G F004 1 R/W 1
[10 , 230] V
Tiempo Antirrebotes Tarjeta G - Board G Debounce Time Settings
0x1FE8 Debounce Time A_G F004 1 R/W 1 [1 , 50] ms
0x1FE9 Debounce Time B_G F004 1 R/W 1 [1 , 50] ms
0x208D Debounce Time C_G F004 1 R/W 1 [1 , 50] ms
0x208E Debounce Time D_G F004 1 R/W 1
[1 , 50] ms
Ajuste Tipo de Entrada Tarjeta G (32 elementos) - Board G Input Type Settings (32 items)
0x1FEA Input Type_G_CC1 F012 1 R/W 1 0=POSITIVE-EDGE
1=NEGATIVE-EDGE
2=POSITIVE
3=NEGATIVE
0x1FEB Input Type_G_CC2 F012 1 R/W 1 0=POSITIVE-EDGE
1=NEGATIVE-EDGE
2=POSITIVE
3=NEGATIVE
... ... ... ... ... ... ... ...
0x2009 Input Type_G_CC32 F012 1 R/W 1 0=POSITIVE-EDGE
1=NEGATIVE-EDGE
2=POSITIVE
3=NEGATIVE
Ajustes Tiempo Retardo Entradas Tarjeta G (32 elementos) - Board G Delay Input Time Settings (32 items)
0x200A Delay Input Time_G_CC1 F005 1 R/W 2 [0 , 60000] ms
0x200C Delay Input Time_G_CC2 F005 1 R/W 2 [0 , 60000] ms
... ... ... ... ... ... ... ...
0x2048 Delay Input Time_G_CC32 F005 1 R/W 2
[0 , 60000] ms
Ajustes Lógica de Salidas Tarjeta G (16 elementos) - Board G Output Logic Settings (16 items)
0x204A Output Logic_G_01 F012 1 R/W 1 0=POSITIVE
1=NEGATIVE
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
