B-62 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x20B7 Channelx1a_G_01 F003 1000 R/W 2 [0,950 , 1,050]
0x20B9 Channelx1a_G_02 F003 1000 R/W 2 [0,950 , 1,050]
0x20BB Channelx1a_G_03 F003 1000 R/W 2 [0,950 , 1,050]
0x20BD Channelx1a_G_04 F003 1000 R/W 2 [0,950 , 1,050]
0x20BF Channelx1a_G_05 F003 1000 R/W 2 [0,950 , 1,050]
0x20C1 Channelx1a_G_06 F003 1000 R/W 2 [0,950 , 1,050]
0x20C3 Channelx1a_G_07 F003 1000 R/W 2 [0,950 , 1,050]
0x20C5 Channelx1a_G_08 F003 1000 R/W 2 [0,950 , 1,050]
0x20C7 Channelx1b_G_01 F004 1000 R/W 1 [-1000 , 1000]
0x20C8 Channelx1b_G_02 F004 1000 R/W 1 [-1000 , 1000]
0x20C9 Channelx1b_G_03 F004 1000 R/W 1 [-1000 , 1000]
0x20CA Channelx1b_G_04 F004 1000 R/W 1 [-1000 , 1000]
0x20CB Channelx1b_G_05 F004 1000 R/W 1 [-1000 , 1000]
0x20CC Channelx1b_G_06 F004 1000 R/W 1 [-1000 , 1000]
0x20CD Channelx1b_G_07 F004 1000 R/W 1 [-1000 , 1000]
0x20CE Channelx1b_G_08 F004 1000 R/W 1 [-1000 , 1000]
0x20CF Channelx10a_G_01 F003 1000 R/W 2 [0,950 , 1,050]
0x20D1 Channelx10a_G_02 F003 1000 R/W 2 [0,950 , 1,050]
0x20D3 Channelx10a_G_03 F003 1000 R/W 2 [0,950 , 1,050]
0x20D5 Channelx10a_G_04 F003 1000 R/W 2 [0,950 , 1,050]
0x20D7 Channelx10a_G_05 F003 1000 R/W 2 [0,950 , 1,050]
0x20D9 Channelx10a_G_06 F003 1000 R/W 2 [0,950 , 1,050]
0x20DB Channelx10a_G_07 F003 1000 R/W 2 [0,950 , 1,050]
0x20DD Channelx10a_G_08 F003 1000 R/W 2 [0,950 , 1,050]
0x20DF Channelx10b_G_01 F004 1000 R/W 1 [-1000 , 1000]
0x20E0 Channelx10b_G_02 F004 1000 R/W 1 [-1000 , 1000]
0x20E1 Channelx10b_G_03 F004 1000 R/W 1 [-1000 , 1000]
0x20E2 Channelx10b_G_04 F004 1000 R/W 1 [-1000 , 1000]
0x20E3 Channelx10b_G_05 F004 1000 R/W 1 [-1000 , 1000]
0x20E4 Channelx10b_G_06 F004 1000 R/W 1 [-1000 , 1000]
0x20E5 Channelx10b_G_07 F004 1000 R/W 1 [-1000 , 1000]
0x20E6 Channelx10b_G_08 F004 1000 R/W 1 [-1000 , 1000]
0x20E7 Calibration Type_G F012 1000 R/W 1 0=NONE
1=OFFSET
2=CALIBRATION
3=GET CALIBRATION
0x2189 Confirmation address W 1
Ajustes Tarjeta H (MODULO CIO) - Board H Settings (CIO MODULE)
Ajustes Tipo Tarjeta H - Board H Board Type Settings
0x2F5B I/O Board Type_H F012 1 R/W 1 0=NONE
1=16INP + 8OUT
2=8INP + 8OUT + SUPV
4=32INP
5=16INP + 8ANA
Ajustes de Tensión Tarjeta H - Board H Voltage Settings
0x2F5C Voltage Threshold A_H F004 1 R/W 1 [10 , 230] V
0x2F5D Voltage Threshold B_H F004 1 R/W 1 [10 , 230] V
0x3001 Voltage Threshold C_H F004 1 R/W 1 [10 , 230] V
0x3002 Voltage Threshold D_H F004 1 R/W 1
[10 , 230] V
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
