APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-63
Tiempo Antirrebotes Tarjeta H - Board H Debounce Time Settings
0x2F5E Debounce Time A_H F004 1 R/W 1 [1 , 50] ms
0x2F5F Debounce Time B_H F004 1 R/W 1 [1 , 50] ms
0x3003 Debounce Time C_H F004 1 R/W 1 [1 , 50] ms
0x3004 Debounce Time D_H F004 1 R/W 1
[1 , 50] ms
Ajuste Tipo de Entrada Tarjeta H (32 elementos) - Board H Input Type Settings (32 items)
0x2F60 Input Type_H_CC1 F012 1 R/W 1 0=POSITIVE-EDGE
1=NEGATIVE-EDGE
2=POSITIVE
3=NEGATIVE
0x2F61 Input Type_H_CC2 F012 1 R/W 1 0=POSITIVE-EDGE
1=NEGATIVE-EDGE
2=POSITIVE
3=NEGATIVE
... ... ... ... ... ... ... ...
0x2F7F Input Type_H_CC32 F012 1 R/W 1 0=POSITIVE-EDGE
1=NEGATIVE-EDGE
2=POSITIVE
3=NEGATIVE
Ajuste Tiempo Retardo Entradas Tarjeta H (32 elementos) - Board H Delay Input Time Settings (32 items)
0x2F80 Delay Input Time_H_CC1 F005 1 R/W 2 [0 , 60000] ms
0x2F82 Delay Input Time_H_CC2 F005 1 R/W 2 [0 , 60000] ms
... ... ... ... ... ... ... ...
0x2FBE Delay Input Time_H_CC32 F005 1 R/W 2
[0 , 60000] ms
Ajuste Lógica de Salidas Tarjeta H (16 elementos) - Board H Output Logic Settings (16 items)
0x2FC0 Output Logic_H_01 F012 1 R/W 1 0=POSITIVE
1=NEGATIVE
0x2FC1 Output Logic_H_02 F012 1 R/W 1 0=POSITIVE
1=NEGATIVE
... ... ... ... ... ... ... ...
0x2FCF Output Logic_H_16 F012 1 R/W 1 0=POSITIVE
1=NEGATIVE
Ajuste Tipo de Salidas Tarjeta H (16 elementos) - Board H Output Type Settings (16 items)
0x2FD0 Output Type_H_01 F012 1 R/W 1 0=NORMAL
1=PULSE
2=LATCH
0x2FD1 Output Type_H_02 F012 1 R/W 1 0=NORMAL
1=PULSE
2=LATCH
... ... ... ... ... ... ... ...
0x2FDF Output Type_H_16 F012 1 R/W 1 0=NORMAL
1=PULSE
2=LATCH
Ajuste Tiempo Pulso de Salida Tarjeta H - Board H Pulse Output Time Settings (16 items)
0x2FE0 Pulse Output Time_H_01 F005 1 R/W 2 [0 , 60000] ms
0x2FE2 Pulse Output Time_H_02 F005 1 R/W 2 [0 , 60000] ms
... ... ... ... ... ... ... ...
0x2FFE Pulse Output Time_H_16 F005 1 R/W 2 [0 , 60000] ms
0x3000 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
