B-64 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
Ajuste Rango de Entrada Analogica H (8 elementos) - Board H Analog Input Range Settings (8 items)
0x3005 Range_H_01 F012 1 R/W 1 0=NONE
1=-1 to 0 mA
2= 0 to 1mA
3=-1 to 1mA
4= 0 to 5 mA
5= 0 to 10mA
6= 0 to 20mA
7= 4 to 20mA
... ... ... ... ... ... ... ...
0x300C Range_H_08 F012 1 R/W 1 0=NONE
1=-1 to 0 mA
2= 0 to 1mA
3=-1 to 1mA
4= 0 to 5 mA
5= 0 to 10mA
6= 0 to 20mA
7= 4 to 20mA
Ajuste Rango de Medida de Entrada Analógica H (8 elementos) - Board H: Analog Input Measurement Range (8 items)
0x300D Min Value_H_01 F003 1 R/W 2 [-9999.99 , 9999.99]
0x300F Min Value_H_02 F003 1 R/W 2 [-9999.99 , 9999.99]
... ... ... ... ... ... ... ...
0x301B Min Value_H_08 F003 1 R/W 2 [-9999.99 , 9999.99]
0x301D Max Value_H_01 F003 1 R/W 2 [-9999.99 , 9999.99]
0x301F Max Value_H_02 F003 1 R/W 2 [-9999.99 , 9999.99]
... ... ... ... ... ... ... ...
0x302B Max Value_H_08 F003 1 R/W 2 [-9999.99 , 9999.99]
0x302D Channelx1a_H_01 F003 1000 R/W 2 [0,950 , 1,050]
0x302F Channelx1a_H_02 F003 1000 R/W 2 [0,950 , 1,050]
0x3031 Channelx1a_H_03 F003 1000 R/W 2 [0,950 , 1,050]
0x3033 Channelx1a_H_04 F003 1000 R/W 2 [0,950 , 1,050]
0x3035 Channelx1a_H_05 F003 1000 R/W 2 [0,950 , 1,050]
0x3037 Channelx1a_H_06 F003 1000 R/W 2 [0,950 , 1,050]
0x3039 Channelx1a_H_07 F003 1000 R/W 2 [0,950 , 1,050]
0x303B Channelx1a_H_08 F003 1000 R/W 2 [0,950 , 1,050]
0x303D Channelx1b_H_01 F004 1000 R/W 1 [-1000 , 1000]
0x303E Channelx1b_H_02 F004 1000 R/W 1
[-1000 , 1000]
0x303F Channelx1b_H_03 F004 1000 R/W 1 [-1000 , 1000]
0x3040 Channelx1b_H_04 F004 1000 R/W 1 [-1000 , 1000]
0x3041 Channelx1b_H_05 F004 1000 R/W 1 [-1000 , 1000]
0x3042 Channelx1b_H_06 F004 1000 R/W 1 [-1000 , 1000]
0x3043 Channelx1b_H_07 F004 1000 R/W 1 [-1000 , 1000]
0x3044 Channelx1b_H_08 F004 1000 R/W 1 [-1000 , 1000]
0x3045 Channelx10a_H_01 F003 1000 R/W 2 [0,950 , 1,050]
0x3047 Channelx10a_H_02 F003 1000 R/W 2 [0,950 , 1,050]
0x3049 Channelx10a_H_03 F003 1000 R/W 2 [0,950 , 1,050]
0x304B Channelx10a_H_04 F003 1000 R/W 2 [0,950 , 1,050]
0x304D Channelx10a_H_05 F003 1000 R/W 2 [0,950 , 1,050]
0x304F Channelx10a_H_06 F003 1000 R/W 2
[0,950 , 1,050]
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
