APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-65
0x3051 Channelx10a_H_07 F003 1000 R/W 2 [0,950 , 1,050]
0x3053 Channelx10a_H_08 F003 1000 R/W 2 [0,950 , 1,050]
0x3055 Channelx10b_H_01 F004 1000 R/W 1 [-1000 , 1000]
0x3056 Channelx10b_H_02 F004 1000 R/W 1 [-1000 , 1000]
0x3057 Channelx10b_H_03 F004 1000 R/W 1 [-1000 , 1000]
0x3058 Channelx10b_H_04 F004 1000 R/W 1 [-1000 , 1000]
0x3059 Channelx10b_H_05 F004 1000 R/W 1 [-1000 , 1000]
0x305A Channelx10b_H_06 F004 1000 R/W 1 [-1000 , 1000]
0x305B Channelx10b_H_07 F004 1000 R/W 1 [-1000 , 1000]
0x305C Channelx10b_H_08 F004 1000 R/W 1 [-1000 , 1000]
0x305D Calibration Type_H F012 1000 R/W 1 0=NONE
1=OFFSET
2=CALIBRATION
3=GET CALIBRATION
0x30FF Confirmation address W 1
Ajustes Tarjeta J (MODULO CIO) - Board J Settings (CIO MODULE)
Ajustes Tipo Tarjeta J - Board J Board Type Settings
0x3100 I/O Board Type_J F012 1 R/W 1 0=NONE
1=16INP + 8OUT
2=8INP + 8OUT + SUPV
4=32INP
5=16INP + 8ANA
Ajustes de Tensión Tarjeta J - Board J Voltage Settings
0x3101 Voltage Threshold A_J F004 1 R/W 1 [10 , 230] V
0x3102 Voltage Threshold B_J F004 1 R/W 1 [10 , 230] V
0x31A6 Voltage Threshold C_J F004 1 R/W 1 [10 , 230] V
0x31A7 Voltage Threshold D_J F004 1 R/W 1
[10 , 230] V
Ajustes Tiempo Antirrebotes Tarjeta J - Board J Debounce Time Settings
0x3103 Debounce Time A_J F004 1 R/W 1 [1 , 50] ms
0x3104 Debounce Time B_J F004 1 R/W 1 [1 , 50] ms
0x31A8 Debounce Time C_J F004 1 R/W 1 [1 , 50] ms
0x31A9 Debounce Time D_J F004 1 R/W 1
[1 , 50] ms
Ajuste Tipo de Entrada Tarjeta J (32 elementos) - Board J Input Type Settings (32 items)
0x3105 Input Type_J_CC1 F012 1 R/W 1 0=POSITIVE-EDGE
1=NEGATIVE-EDGE
2=POSITIVE
3=NEGATIVE
0x3106 Input Type_J_CC2 F012 1 R/W 1 0=POSITIVE-EDGE
1=NEGATIVE-EDGE
2=POSITIVE
3=NEGATIVE
... ... ... ... ... ... ... ...
0x3124 Input Type_J_CC32 F012 1 R/W 1 0=POSITIVE-EDGE
1=NEGATIVE-EDGE
2=POSITIVE
3=NEGATIVE
Ajustes Tiempo Retardo Entradas Tarjeta J (32 elementos) - Board J Delay Input Time Settings (32 items)
0x3125 Delay Input Time_J_CC1 F005 1 R/W 2 [0 , 60000] ms
0x3127 Delay Input Time_J_CC2 F005 1 R/W 2 [0 , 60000] ms
... ... ... ... ... ... ...
...
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
