B-66 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x3163 Delay Input Time_J_CC32 F005 1 R/W 2 [0 , 60000] ms
Ajustes Lógica de Salidas Tarjeta J (16 elementos) - Board J Output Logic Settings (16 items)
0x3165 Output Logic_J_01 F012 1 R/W 1 0=POSITIVE
1=NEGATIVE
0x3166 Output Logic_J_02 F012 1 R/W 1 0=POSITIVE
1=NEGATIVE
... ... ... ... ... ... ... ...
0x3174 Output Logic_J_16 F012 1 R/W 1 0=POSITIVE
1=NEGATIVE
Ajustes Tipo de Salidas Tarjeta J (16 elementos) - Board J Output Type Settings (16 items)
0x3175 Output Type_J_01 F012 1 R/W 1 0=NORMAL
1=PULSE
2=LATCH
0x3176 Output Type_J_02 F012 1 R/W 1 0=NORMAL
1=PULSE
2=LATCH
... ... ... ... ... ... ... ...
0x3184 Output Type_J_16 F012 1 R/W 1 0=NORMAL
1=PULSE
2=LATCH
Ajustes Tiempo Pulso de Salida Tarjeta J - Board J Pulse Output Time Settings (16 items)
0x3185 Pulse Output Time_J_01 F005 1 R/W 2 [0 , 60000] ms
0x3187 Pulse Output Time_J_02 F005 1 R/W 2 [0 , 60000] ms
... ... ... ... ... ... ... ...
0x31A3 Pulse Output Time_J_16 F005 1 R/W 2 [0 , 60000] ms
0x31A5 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
Ajuste Rango de Entrada Analogica J (8 elementos) - Board J Analog Input Range Settings (8 items)
0x31AA Range_J_01 F012 1 R/W 1 0=NONE
1=-1 to 0 mA
2= 0 to 1mA
3=-1 to 1mA
4= 0 to 5 mA
5= 0 to 10mA
6= 0 to 20mA
7= 4 to 20mA
... ... ... ... ... ... ... ...
0x31B1 Range_J_08 F012 1 R/W 1 0=NONE
1=-1 to 0 mA
2= 0 to 1mA
3=-1 to 1mA
4= 0 to 5 mA
5= 0 to 10mA
6= 0 to 20mA
7= 4 to 20mA
Ajustes Rango de Medida de Entrada Analógica J (8 elementos) - Board J Analog Input Measurement Range Settings (8 items)
0x31B2 Min Value_J_01 F003 1 R/W 2 [-9999.99 , 9999.99]
0x31B4 Min Value_J_02 F003 1 R/W 2 [-9999.99 , 9999.99]
... ... ... ... ... ... ... ...
0x31C0 Min Value_J_08 F003 1 R/W 2
[-9999.99 , 9999.99]
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
