APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-67
0x31C2 Max Value_J_01 F003 1 R/W 2 [-9999.99 , 9999.99]
0x31C4 Max Value_J_02 F003 1 R/W 2 [-9999.99 , 9999.99]
... ... ... ... ... ... ... ...
0x31D0 Max Value_J_08 F003 1 R/W 2 [-9999.99 , 9999.99]
0x31D2 Channelx1a_J_01 F003 1000 R/W 2 [0,950 , 1,050]
0x31D4 Channelx1a_J_02 F003 1000 R/W 2 [0,950 , 1,050]
0x31D6 Channelx1a_J_03 F003 1000 R/W 2 [0,950 , 1,050]
0x31D8 Channelx1a_J_04 F003 1000 R/W 2 [0,950 , 1,050]
0x31DA Channelx1a_J_05 F003 1000 R/W 2 [0,950 , 1,050]
0x31DC Channelx1a_J_06 F003 1000 R/W 2 [0,950 , 1,050]
0x31DE Channelx1a_J_07 F003 1000 R/W 2 [0,950 , 1,050]
0x31E0 Channelx1a_J_08 F003 1000 R/W 2 [0,950 , 1,050]
0x31E2 Channelx1b_J_01 F004 1000 R/W 1 [-1000 , 1000]
0x31E3 Channelx1b_J_02 F004 1000 R/W 1 [-1000 , 1000]
0x31E4 Channelx1b_J_03 F004 1000 R/W 1 [-1000 , 1000]
0x31E5 Channelx1b_J_04 F004 1000 R/W 1 [-1000 , 1000]
0x31E6 Channelx1b_J_05 F004 1000 R/W 1 [-1000 , 1000]
0x31E7 Channelx1b_J_06 F004 1000 R/W 1 [-1000 , 1000]
0x31E8 Channelx1b_J_07 F004
1000 R/W 1 [-1000 , 1000]
0x31E9 Channelx1b_J_08 F004 1000 R/W 1 [-1000 , 1000]
0x31EA Channelx10a_J_01 F003 1000 R/W 2 [0,950 , 1,050]
0x31EC Channelx10a_J_02 F003 1000 R/W 2 [0,950 , 1,050]
0x31EE Channelx10a_J_03 F003 1000 R/W 2 [0,950 , 1,050]
0x31F0 Channelx10a_J_04 F003 1000 R/W 2 [0,950 , 1,050]
0x31F2 Channelx10a_J_05 F003 1000 R/W 2 [0,950 , 1,050]
0x31F4 Channelx10a_J_06 F003 1000 R/W 2 [0,950 , 1,050]
0x31F6 Channelx10a_J_07 F003 1000 R/W 2 [0,950 , 1,050]
0x31F8 Channelx10a_J_08 F003 1000 R/W 2 [0,950 , 1,050]
0x31FA Channelx10b_J_01 F004 1000 R/W 1 [-1000 , 1000]
0x31FB Channelx10b_J_02 F004 1000 R/W 1 [-1000 , 1000]
0x31FC Channelx10b_J_03 F004 1000 R/W 1 [-1000 , 1000]
0x31FD Channelx10b_J_04 F004 1000 R/W 1 [-1000 , 1000]
0x31FE Channelx10b_J_05 F004 1000 R/W 1 [-1000 , 1000]
0x31FF Channelx10b_J_06 F004 1000 R/W 1 [-1000 , 1000]
0x3200 Channelx10b_J_07 F004 1000 R/W 1 [-1000 , 1000]
0x3201 Channelx10b_J_08 F004 1000 R/W 1 [-1000 , 1000]
0x3202 Calibration Type_J F012 1000 R/W 1 0=NONE
1=OFFSET
2=CALIBRATION
3=GET CALIBRATION
0x32A4 Confirmation address W 1
Ajustes Generales - General Settings
0x218A Phase CT Ratio F003 1 R/W 2 [1.0 , 6000.0]
0x218C Ground CT Ratio F003 1 R/W 2 [1.0 , 6000.0]
0x218E Stv Ground CT Ratio F003 1 R/W 2 [1.0 , 6000.0]
0x2190 Phase VT Ratio F003 1 R/W 2 [1.0 , 6000.0]
0x2192 Phase VT Connection F012 1 R/W 1 0=WYE
1=DELTA
0x2193 Nominal Voltage F003 1 R/W 2
[1.0 , 250.0] V
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
