B-68 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x2195 Nominal Frequency F012 1 R/W 1 0=50 Hz
1=60 Hz
0x2196 Phase Rotation F012 1 R/W 1 0=ABC
1=ACB
0x2197 Frequency Reference F012 1 R/W 1 0=VI
1=VII
2=VIII
0x2198 Auxiliary Voltage F012 1 R/W 1 0=V
X
1=VN
0x2199 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x219B Primary Meter Units F012 1 R/W 1 0=KA_KV
1=A_V
0x219C Device Name F009 1 R/W 8
0x2203 Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Fases Nivel Alto Grupo 1 - Phase IOC High 1 Settings
0x2204 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2205 Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x2206 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x2208 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x220A Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x220C Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x221F Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Fases Nivel Alto Grupo 2 - Phase IOC High 2 Settings
0x2220 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2221 Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x2222 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x2224 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2226 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2228 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x223B Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Fases Nivel Alto Grupo 3 - Phase IOC High 3 Settings
0x223C Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x223D Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x223E Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x2240 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2242 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2244 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2257 Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Fases Nivel Bajo Grupo 1 - Phase IOC Low 1 Settings
0x2258 Function F012 1 R/W 1
0=DISABLED
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
