B-70 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x22E2 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x22E3 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x22E5 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x22E7 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x22E9 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x22FC Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Tierra Grupo 1 - Ground IOC 1 Settings
0x22FD Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x22FE Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x22FF Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x2301 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2303 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2305 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2318 Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Tierra Grupo 2 - Ground IOC 2 Settings
0x2319 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x231A Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x231B Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x231D Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x231F Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2321 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2334 Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Tierra Grupo 3 - Ground IOC 3 Settings
0x2335 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2336 Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x2337 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x2339 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x233B Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x233D Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2350 Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Tierra Sensible Grupo 1 - Sensitive Ground IOC 1 Settings
0x2351 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2352 Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x2353 Pickup Level F003 1 R/W 2 [0.005 , 16.000] A
0x2355 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2357 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2359 Snapshot Events F012 1 R/W 1
0=DISABLED
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
