APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-71
1=ENABLED
0x236C Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Tierra Sensible Grupo 2 - Sensitive Ground IOC 2 Settings
0x236D Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x236E Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x236F Pickup Level F003 1 R/W 2 [0.005 , 16.000] A
0x2371 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2373 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2375 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2388 Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Tierra Sensible Grupo 3 - Sensitive Ground IOC 3 Settings
0x2389 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x238A Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x238B Pickup Level F003 1 R/W 2 [0.005 , 16.000] A
0x238D Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x238F Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2391 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x23A4 Confirmation address W 1
Ajustes Sobreintensidad Temporizada de Fases Nivel Alto Grupo 1 - Phase TOC High 1 Settings
0x23A5 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x23A6 Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x23A7 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x23A9 Curve F012 1 R/W 1 0=IEEE Ext Inv
1=IEEE Very Inv
2=IEEE Mod Inv
3=IEC Curve A
4=IEC Curve B
5=IEC Curve C
6=IEC Long-Time Inv
7=IEC Short-Time Inv
8=IAC Ext Inv
9=IAC Very Inv
10=IAC Mod Inv
11=ANSI Ext Inv
12=ANSI Very Inv
13=ANSI Norm Inv
14=ANSI Mod Inv
15=I2t
16=Definite Time
17=Rectifier Curve
18=User Curve A
19=User Curve B
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
