B-72 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
20=User Curve C
21=User Curve D
0x23AA TD Multiplier F003 1 R/W 2 [0.00 , 900.00] s
0x23AC Reset F012 1 R/W 1
0=INSTANTANEOUS
Ajustes Sobreintensidad Temporizada de Fases Nivel Alto Grupo 1 - Phase TOC High 1 Settings(cont.)
1=LINEAR
0x23AD Voltage Restraint F012 1 R/W 1 0=DISABLED
1=ENABLED
0x23AE Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x23C1 Confirmation address W 1
Ajustes Sobreintensidad Temporizada de Fases Nivel Alto Grupo 2 - Phase TOC High 2 Settings
0x23C2 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x23C3 Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x23C4 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x23C6 Curve F012 1 R/W 1 0=IEEE Ext Inv
1=IEEE Very Inv
2=IEEE Mod Inv
3=IEC Curve A
4=IEC Curve B
5=IEC Curve C
6=IEC Long-Time Inv
7=IEC Short-Time Inv
8=IAC Ext Inv
9=IAC Very Inv
10=IAC Mod Inv
11=ANSI Ext Inv
12=ANSI Very Inv
13=ANSI Norm Inv
14=ANSI Mod Inv
15=I2t
16=Definite Time
17=Rectifier Curve
18=User Curve A
19=User Curve B
20=User Curve C
21=User Curve D
0x23C7 TD Multiplier F003 1 R/W 2 [0.00 , 900.00] s
0x23C9 Reset F012 1 R/W 1 0=INSTANTANEOUS
1=LINEAR
0x23CA Voltage Restraint F012 1 R/W 1 0=DISABLED
1=ENABLED
0x23CB Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x23DE Confirmation address W 1
Ajustes Sobreintensidad Temporizada de Fases Nivel Alto Grupo 3 - Phase TOC High 3 Settings
0x23DF Function F012 1 R/W 1 0=DISABLED
1=ENABLED
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
