B-76 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
14=ANSI Mod Inv
15=I2t
16=Definite Time
17=Rectifier Curve
18=User Curve A
19=User Curve B
20=User Curve C
21=User Curve D
0x2452 TD Multiplier F003 1 R/W 2 [0.00 , 900.00] s
0x2454 Reset F012 1 R/W 1 0=INSTANTANEOUS
1=LINEAR
0x2455 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2468 Confirmation address W 1
Ajustes Sobreintensidad Temporizada de Tierra Grupo 2 - Ground TOC 2 Settings
0x2469 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x246A Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x246B Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x246D Curve F012 1 R/W 1 0=IEEE Ext Inv
1=IEEE Very Inv
2=IEEE Mod Inv
3=IEC Curve A
4=IEC Curve B
5=IEC Curve C
6=IEC Long-Time Inv
7=IEC Short-Time Inv
8=IAC Ext Inv
9=IAC Very Inv
10=IAC Mod Inv
11=ANSI Ext Inv
12=ANSI Very Inv
13=ANSI Norm Inv
14=ANSI Mod Inv
15=I2t
16=Definite Time
17=Rectifier Curve
18=User Curve A
19=User Curve B
20=User Curve C
21=User Curve D
0x246E TD Multiplier F003 1 R/W 2 [0.00 , 900.00] s
0x2470 Reset F012 1 R/W 1 0=INSTANTANEOUS
1=LINEAR
0x2471 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2484 Confirmation address W 1
Ajustes Sobreintensidad Temporizada de Tierra Grupo 3 - Ground TOC 3 Settings
0x2485 Function F012 1 R/W 1
0=DISABLED
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
