APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-77
1=ENABLED
0x2486 Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x2487 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x2489 Curve F012 1 R/W 1 0=IEEE Ext Inv
1=IEEE Very Inv
2=IEEE Mod Inv
3=IEC Curve A
4=IEC Curve B
5=IEC Curve C
6=IEC Long-Time Inv
7=IEC Short-Time Inv
8=IAC Ext Inv
9=IAC Very Inv
10=IAC Mod Inv
11=ANSI Ext Inv
12=ANSI Very Inv
13=ANSI Norm Inv
14=ANSI Mod Inv
15=I2t
16=Definite Time
17=Rectifier Curve
18=User Curve A
19=User Curve B
20=User Curve C
21=User Curve D
0x248A TD Multiplier F003 1 R/W 2 [0.00 , 900.00] s
0x248C Reset F012 1 R/W 1 0=INSTANTANEOUS
1=LINEAR
0x248D Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x24A0 Confirmation address W 1
Ajustes Sobreintensidad Temporizada de Tierra Sensible Grupo 1 - Sensitive Ground TOC 1 Settings
0x24A1 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x24A2 Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x24A3 Pickup Level F003 1 R/W 2 [0.005 , 16.000] A
0x24A5 Curve F012 1 R/W 1 0=IEEE Ext Inv
1=IEEE Very Inv
2=IEEE Mod Inv
3=IEC Curve A
4=IEC Curve B
5=IEC Curve C
6=IEC Long-Time Inv
7=IEC Short-Time Inv
8=IAC Ext Inv
9=IAC Very Inv
10=IAC Mod Inv
11=ANSI Ext Inv
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
To Next Page
