APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-83
0x2666 Confirmation address W 1
Ajustes Unidad Direccional de Neutro Grupo 2 - Neutral Directional 2 Settings
0x2667 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2668 MTA F003 1 R/W 2 [-90 , 90] Deg
0x266A Direction F012 1 R/W 1 0=REVERSE
1=FORWARD
0x266B Polarization F012 1 R/W 1 0=VO
1=IP
2=VO + IP
3=VO*IP
0x266C Block Logic F012 1 R/W 1 0=PERMISSION
1=BLOCK
0x266D Pol V Threshold F003 1 R/W 2
[0 , 300] V
0x266F Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2682 Confirmation address W 1
Ajustes Unidad Direccional de Neutro Grupo 3 - Neutral Directional 3 Settings
0x2683 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2684 MTA F003 1 R/W 2 [-90 , 90] Deg
0x2686 Direction F012 1 R/W 1 0=REVERSE
1=FORWARD
0x2687 Polarization F012 1 R/W 1 0=VO
1=IP
2=VO + IP
3=VO*IP
0x2688 Block Logic F012 1 R/W 1 0=PERMISSION
1=BLOCK
0x2689 Pol V Threshold F003 1 R/W 2 [0 , 300] V
0x268B Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x269E Confirmation address W 1
Ajustes Unidad Direccional de Tierra Grupo 1 - Ground Directional 1 Settings
0x269F Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x26A0 MTA F003 1 R/W 2 [-90 , 90] Deg
0x26A2 Direction F012 1 R/W 1 0=REVERSE
1=FORWARD
0x26A3 Polarization F012 1 R/W 1
0=VO
1=IP
2=VO + IP
3=VO*IP
0x26A4 Block Logic F012 1 R/W 1 0=PERMISSION
1=BLOCK
0x26A5 Pol V Threshold F003 1 R/W 2 [0 , 300] V
0x26A7 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x26BA Confirmation address W 1
Ajustes Unidad Direccional de Tierra Grupo 2 - Ground Directional 2 Settings
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
