B-82 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x25FD Direction F012 1 R/W 1 0=REVERSE
1=FORWARD
0x25FE Block Logic F012 1 R/W 1 0=PERMISSION
1=BLOCK
0x25FF Pol V Threshold F003 1 R/W 2 [0 , 300] V
0x2601 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2602 Voltage Memory Time F003 1000 R/W 2 [0,00 , 3,00] s
0x2614 Confirmation address W 1
Ajustes Unidad Direccional de Fases Grupo 2 - Phase Directional 2 Settings
0x2615 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2616 MTA F003 1 R/W 2 [-90 , 90] Deg
0x2618 Direction F012 1 R/W 1 0=REVERSE
1=FORWARD
0x2619 Block Logic F012 1 R/W 1 0=PERMISSION
1=BLOCK
0x261A Pol V Threshold F003 1 R/W 2 [0 , 300] V
0x261C Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x261D Voltage Memory Time F003 1000 R/W 2 [0,00 , 3,00] s
0x262F Confirmation address W 1
Ajustes Unidad Direccional de Fases Grupo 3 - Phase Directional 3 Settings
0x2630 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2631 MTA F003 1 R/W 2 [-90 , 90] Deg
0x2633 Direction F012 1 R/W 1 0=REVERSE
1=FORWARD
0x2634 Block Logic F012 1 R/W 1 0=PERMISSION
1=BLOCK
0x2635 Pol V Threshold F003 1 R/W 2 [0 , 300] V
0x2637 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2638 Voltage Memory Time F003 1000 R/W 2 [0,00 , 3,00] s
0x264A Confirmation address W 1
Ajustes Unidad Direccional de Neutro Grupo 1 - Neutral Directional 1 Settings
0x264B Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x264C MTA F003 1 R/W 2 [-90 , 90] Deg
0x264E Direction F012 1 R/W 1 0=REVERSE
1=FORWARD
0x264F Polarization F012 1 R/W 1 0=VO
1=IP
2=VO + IP
3=VO*IP
0x2650 Block Logic F012 1 R/W 1 0=PERMISSION
1=BLOCK
0x2651 Pol V Threshold F003 1 R/W 2 [0 , 300] V
0x2653 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
