APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-81
1=ENABLED
0x256E Pickup Level F003 1 R/W 2 [3 , 300] V
0x2570 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2572 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2574 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2587 Confirmation address W 1
Ajustes Sobretensión de Fases Secuencia Negativa Grupo 3 - Negative Sequence OV 3 Settings
0x2588 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2589 Pickup Level F003 1 R/W 2 [3 , 300] V
0x258B Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x258D Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x258F Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x25A2 Confirmation address W 1
Ajustes Imagen Térmica Grupo 1 - Thermal Model 1 Settings
0x25A3 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x25A4 Heat Time Constant F003 1 R/W 2 [3.0 , 600.0] min
0x25A6 Cool Time Constant F003 1 R/W 2 [1.00 , 6.00]
0x25A8 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x25AA Alarm Level F003 1 R/W 2 [1.0 , 110.0] %
0x25AC Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x25BF Confirmation address W 1
Ajustes Imagen Térmica Grupo 2 - Thermal Model 2 Settings
0x25C0 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x25C1 Heat Time Constant F003 1 R/W 2 [3.0 , 600.0] min
0x25C3 Cool Time Constant F003 1 R/W 2 [1.00 , 6.00]
0x25C5 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x25C7 Alarm Level F003 1 R/W 2 [1.0 , 110.0] %
0x25C9 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x25DC Confirmation address W 1
Ajustes Imagen Térmica Grupo 3 - Thermal Model 3 Settings
0x25DD Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x25DE Heat Time Constant F003 1 R/W 2 [3.0 , 600.0] min
0x25E0 Cool Time Constant F003 1 R/W 2 [1.00 , 6.00]
0x25E2 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x25E4 Alarm Level F003 1 R/W 2 [1.0 , 110.0] %
0x25E6 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x25F9 Confirmation address W 1
Ajustes Unidad Direccional de Fases Grupo 1 - Phase Directional 1 Settings
0x25FA Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x25FB MTA F003 1 R/W 2
[-90 , 90] Deg
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
