B-80 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x2500 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2513 Confirmation address W 1
Ajustes Subtensión de Fases Grupo 2 - Phase UV 2 Settings
0x2514 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2515 Mode F012 1 R/W 1 0=PHASE-PHASE
1=PHASE-GROUND
0x2516 Pickup Level F003 1 R/W 2 [3 , 300] V
0x2518 Curve F012 1 R/W 1 0=DEFINITE TIME
1=INVERSE TIME
0x2519 Delay F003 1 R/W 2 [0.00 , 900.00] s
0x251B Minimum Voltage F003 1 R/W 2 [0 , 300] V
0x251D Logic F012 1 R/W 1 0=ANY PHASE
1=TWO PHASES
2=ALL PHASES
0x251E Supervised by 52 F012 1 R/W 1 0=DISABLED
1=ENABLED
0x251F Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2532 Confirmation address
W 1
Ajustes Subtensión de Fases Grupo 3 - Phase UV 3 Settings
0x2533 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2534 Mode F012 1 R/W 1 0=PHASE-PHASE
1=PHASE-GROUND
0x2535 Pickup Level F003 1 R/W 2 [3 , 300] V
0x2537 Curve F012 1 R/W 1 0=DEFINITE TIME
1=INVERSE TIME
0x2538 Delay F003 1 R/W 2 [0.00 , 900.00] s
0x253A Minimum Voltage F003 1 R/W 2 [0 , 300] V
0x253C Logic F012 1 R/W 1 0=ANY PHASE
1=TWO PHASES
2=ALL PHASES
0x253D Supervised by 52 F012 1 R/W 1 0=DISABLED
1=ENABLED
0x253E Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2551 Confirmation address
W 1
Ajustes Sobretensión de Fases Secuencia Negativa Grupo 1 - Negative Sequence OV 1 Settings
0x2552 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2553 Pickup Level F003 1 R/W 2 [3 , 300] V
0x2555 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2557 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2559 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x256C Confirmation address W 1
Ajustes Sobretensión de Fases Secuencia Negativa Grupo 2 - Negative Sequence OV 2 Settings
0x256D Function F012 1 R/W 1
0=DISABLED
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
