B-90 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x2956 Confirmation address W 1
Ajustes Sobreintensidad Temporizada de Secuencia Negativa Grupo 3 - Negative Sequence TOC 3 Settings
0x2957 Function F012 1 R/W 1
0=DISABLED
1=ENABLED
0x2958 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x295A Curve F012 1 R/W 1 0=IEEE Ext Inv
1=IEEE Very Inv
2=IEEE Mod Inv
3=IEC Curve A
4=IEC Curve B
5=IEC Curve C
6=IEC Long-Time Inv
7=IEC Short-Time Inv
8=IAC Ext Inv
9=IAC Very Inv
10=IAC Mod Inv
11=ANSI Ext Inv
12=ANSI Very Inv
13=ANSI Norm Inv
14=ANSI Mod Inv
15=I2t
16=Definite Time
17=Rectifier Curve
18=User Curve A
19=User Curve B
20=User Curve C
21=User Curve D
0x295B TD Multiplier F003 1 R/W 2 [0.00 , 900.00] s
0x295D Reset F012 1 R/W 1 0=INSTANTANEOUS
1=LINEAR
0x295E Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2971 Confirmation address W 1
Ajustes Sobrefrecuencia Grupo 1 - Overfrequency 1 Settings
0x2972 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2973 Pickup Level F003 1 R/W 2 [20.00 , 65.00] Hz
0x2975 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2977 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2979 Minimum Voltage F003 1 R/W 2 [10 , 300] V
0x297B Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x298E Confirmation address W 1
Ajustes Sobrefrecuencia Grupo 2 - Overfrequency 2 Settings
0x298F Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2990 Pickup Level F003 1 R/W 2 [20.00 , 65.00] Hz
0x2992 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2994 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2996 Minimum Voltage F003 1 R/W 2
[10 , 300] V
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
