APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-91
0x2998 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x29AB Confirmation address W 1
Ajustes Sobrefrecuencia Grupo 3 - Overfrequency 3 Settings
0x29AC Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x29AD Pickup Level F003 1 R/W 2 [20.00 , 65.00] Hz
0x29AF Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x29B1 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x29B3 Minimum Voltage F003 1 R/W 2 [10 , 300] V
0x29B5 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x29C8 Confirmation address W 1
Ajustes Subfrecuencia Grupo 1 - Underfrequency 1 Settings
0x29C9 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x29CA Pickup Level F003 1 R/W 2 [20.00 , 65.00] Hz
0x29CC Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x29CE Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x29D0 Minimum Voltage F003 1 R/W 2 [10 , 300] V
0x29D2 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x29E5 Confirmation address W 1
Ajustes Subfrecuencia Grupo 2 - Underfrequency 2 Settings
0x29E6 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x29E7 Pickup Level F003 1 R/W 2 [20.00 , 65.00] Hz
0x29E9 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x29EB Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x29ED Minimum Voltage F003 1 R/W 2 [10 , 300] V
0x29EF Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2A02 Confirmation address W 1
Ajustes Subfrecuencia Grupo 3 - Underfrequency 3 Settings
0x2A03 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2A04 Pickup Level F003 1 R/W 2 [20.00 , 65.00] Hz
0x2A06 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2A08 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2A0A Minimum Voltage F003 1 R/W 2 [10 , 300] V
0x2A0C Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2A1F Confirmation address W 1
Ajustes Oscilografía - Oscillography Settings
0x2A7C Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2A7D Trigger Position F004 1 R/W 1 [5 , 95] %
0x2A7E Samples/Cycle F012 1 R/W 1 0=64
1=32
2=16
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
