B-92 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
3=8
4=4
0x2A7F Max. Number Osc. F004 1 R/W 1 [1 , 20]
0x2A80 Automatic Overwrite F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2A81 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2A92 Confirmation address W 1
Ajustes Localizador de Faltas - Fault Report Settings
0x2A93 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2A94 Pos Seq Module F003 1 R/W 2 [0.01 , 250.00] Ohm
0x2A96 Pos Seq Angle F003 1 R/W 2 [25 , 90] Deg
0x2A98 Zero Seq Module F003 1 R/W 2 [0.01 , 750.00] Ohm
0x2A9A Zero Seq Angle F003 1 R/W 2 [25 , 90] Deg
0x2A9C Line Length F003 1 R/W 2 [0.0 , 2000.0]
0x2A9E Show Fault On HMI F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2A9F Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2AA0 CT Direction F012 1000 R/W 1 0=REVERSE
1=FORWARD
0x2AB1 Confirmation address W 1
Ajustes de Agrupamiento de Funciones - Setting Groups Settings
0x2AB2 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2AB3 Active Group F012 1 R/W 1 0=GROUP 1
1=GROUP 2
2=GROUP 3
0x2AB4 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2AC7 Confirmation address W 1
Textos Canales Digitales - Osc digital channels text
0x2AC8 Channel 1 Txt F009 1 R/W 16
0x2AD8 Channel 2 Txt F009 1 R/W 16
Textos Canales Digitales - Osc digital channels text(cont.)
0x2AE8 Channel 3 Txt F009 1 R/W 16
0x2AF8 Channel 4 Txt F009 1 R/W 16
0x2B08 Channel 5 Txt F009 1 R/W 16
0x2B18 Channel 6 Txt F009 1 R/W 16
0x2B28 Channel 7 Txt F009 1 R/W 16
0x2B38 Channel 8 Txt F009 1 R/W 16
0x2B48 Channel 9 Txt F009 1 R/W 16
0x2B58 Channel 10 Txt F009 1 R/W 16
0x2B68 Channel 11 Txt F009 1 R/W 16
0x2B78 Channel 12 Txt F009 1 R/W 16
0x2B88 Channel 13 Txt F009 1 R/W 16
0x2B98 Channel 14 Txt F009 1 R/W 16
0x2BA8 Channel 15 Txt F009 1 R/W 16
0x2BB8 Channel 16 Txt F009 1 R/W 16
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
To Next Page
