APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-93
0x2C07 Confirmation address W 1
Ajustes Conductor Roto Grupo 1 - Broken conductor 1 Settings
0x2C08 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2C09 Tap F003 1 R/W 2 [20.0 , 100.0] %
0x2C0B Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2C0D Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2C0E Operation Threshold F003 1 R/W 2 [0.000 , 1.000] A
0x2C20 Confirmation address W 1
Ajustes Conductor Roto Grupo 2 - Broken conductor 2 Settings
0x2C21 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2C22 Tap F003 1 R/W 2 [20.0 , 100.0] %
0x2C24 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2C26 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2C27 Operation Threshold F003 1 R/W 2 [0.000 , 1.000] A
0x2C39 Confirmation address W 1
Ajustes Conductor Roto Grupo 3 - Broken conductor 3 Settings
0x2C3A Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2C3B Tap F003 1 R/W 2 [20.0 , 100.0] %
0x2C3D Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2C3F Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2C40 Operation Threshold F003 1 R/W 2 [0.000 , 1.000] A
0x2C52 Confirmation address W 1
Ajustes Ethernet 1 (or “A”)- ETHERNET 1 (or “A”) Settings
0x2C53 IP Address Oct1 F004 1 R/W 1 [0 , 255]
0x2C54 IP Address Oct2 F004 1 R/W 1 [0 , 255]
0x2C55 IP Address Oct3 F004 1 R/W 1 [0 , 255]
0x2C56 IP Address Oct4 F004 1 R/W 1 [0 , 255]
0x2C57 Netmask Oct1 F004 1 R/W 1 [0 , 255]
0x2C58 Netmask Oct2 F004 1 R/W 1 [0 , 255]
0x2C59 Netmask Oct3 F004 1 R/W 1 [0 , 255]
0x2C5A Netmask Oct4 F004 1 R/W 1 [0 , 255]
0x2C5B Ga teway IP Oct1 F004 1 R/W 1 [0 , 255]
0x2C5C Ga te way IP Oct 2 F004 1 R/W 1 [0 , 255]
0x2C5D Ga te way IP Oct 3 F004 1 R/W 1 [0 , 255]
0x2C5E Ga teway IP Oct4 F004 1 R/W 1
[0 , 255]
0x2C86 Confirmation address W 1
Ajustes Ethernet 2 (or “B”) - ETHERNET 2 (or “B”) Settings
0x2C87 IP Address Oct1 F004 1 R/W 1 [0 , 255]
0x2C88 IP Address Oct2 F004 1 R/W 1 [0 , 255]
0x2C89 IP Address Oct3 F004 1 R/W 1 [0 , 255]
0x2C8A IP Address Oct4 F004 1 R/W 1 [0 , 255]
0x2C8B Netmask Oct1 F004 1 R/W 1 [0 , 255]
0x2C8C Netmask Oct2 F004 1 R/W 1 [0 , 255]
0x2C8D Netmask Oct3 F004 1 R/W 1
[0 , 255]
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
