B-94 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x2C8E Netmask Oct4 F004 1 R/W 1 [0 , 255]
0x2C8F Gate way IP Oct1 F004 1 R/W 1 [0 , 255]
0x2C90 Gat ewa y IP Oct2 F004 1 R/W 1 [0 , 255]
0x2C91 Gat ewa y IP Oct3 F004 1 R/W 1 [0 , 255]
0x2C92 Gat ewa y IP Oct4 F004 1 R/W 1 [0 , 255]
0x2CBA Confirmation address W 1
Ajustes DNP 3.0 Esclavo 1 - DNP 3.0 Slave 1 Settings
0x2CBB Physical Port F012 1 R/W 1 0=NONE
1=COM1
2=COM2
3=NETWORK
0x2CBC Address F005 1 R/W 2 [0 , 65534]
0x2CBE IP Addr Client1 Oct1 F004 1 R/W 1 [0 , 255]
0x2CBF IP Addr Client1 Oct2 F004 1 R/W 1 [0 , 255]
0x2CC0 IP Addr Client1 Oct3 F004 1 R/W 1 [0 , 255]
0x2CC1 IP Addr Client1 Oct4 F004 1 R/W 1 [0 , 255]
0x2CC2 IP Addr Client2 Oct1 F004 1 R/W 1 [0 , 255]
0x2CC3 IP Addr Client2 Oct2 F004 1 R/W 1 [0 , 255]
0x2CC4 IP Addr Client2 Oct3 F004 1 R/W 1 [0 , 255]
0x2CC5 IP Addr Client2 Oct4 F004 1 R/W 1 [0 , 255]
0x2CC6 IP Addr Client3 Oct1 F004 1 R/W 1 [0 , 255]
0x2CC7 IP Addr Client3 Oct2 F004 1 R/W 1 [0 , 255]
0x2CC8 IP Addr Client3 Oct3 F004 1 R/W 1 [0 , 255]
0x2CC9 IP Addr Client3 Oct4 F004 1
R/W 1 [0 , 255]
0x2CCA IP Addr Client4 Oct1 F004 1 R/W 1 [0 , 255]
0x2CCB IP Addr Client4 Oct2 F004 1 R/W 1 [0 , 255]
0x2CCC IP Addr Client4 Oct3 F004 1 R/W 1 [0 , 255]
0x2CCD IP Addr Client4 Oct4 F004 1 R/W 1 [0 , 255]
0x2CCE IP Addr Client5 Oct1 F004 1 R/W 1 [0 , 255]
0x2CCF IP Addr Client5 Oct2 F004 1 R/W 1 [0 , 255]
0x2CD0 IP Addr Client5 Oct3 F004 1 R/W 1 [0 , 255]
0x2CD1 IP Addr Client5 Oct4 F004 1 R/W 1 [0 , 255]
0x2CD2 TCP/UDP Port F005 1 R/W 2 [0 , 65535]
0x2CD4 Unsol Resp Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2CD5 Unsol Resp TimeOut F005 1 R/W 2 [0 , 60] s
0x2CD7 Unsol Resp Max Ret F004 1 R/W 1 [0 , 255]
0x2CD8 Unsol Resp Dest Adr F005 1 R/W 2 [0 , 65519]
0x2CDA Current Scale Factor F012 1 R/W 1 0=0.00001
1=0.0001
2=0.001
3=0.01
4=0.1
5=1
6=10
Ajustes DNP 3.0 Esclavo 1 - DNP 3.0 Slave 1 Settings(cont.)
7=100
8=1000
9=10000
0x2CDB Voltage Scale Factor F012 1 R/W 1
0=0.00001
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
