APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-95
1=0.0001
2=0.001
3=0.01
4=0.1
5=1
6=10
7=100
8=1000
9=10000
0x2CDC Power Scale Factor F012 1 R/W 1 0=0.00001
1=0.0001
2=0.001
3=0.01
4=0.1
5=1
6=10
7=100
8=1000
9=10000
0x2CDD Energy Scale Factor F012 1 R/W 1 0=0.00001
1=0.0001
2=0.001
3=0.01
4=0.1
5=1
6=10
7=100
8=1000
9=10000
0x2CDE Other Scale Factor F012 1 R/W 1 0=0.00001
1=0.0001
2=0.001
3=0.01
4=0.1
5=1
6=10
7=100
8=1000
9=10000
0x2CDF Current Deadband F005 1 R/W 2 [0 , 65535]
0x2CE1 Voltage Deadband F005 1 R/W 2 [0 , 65535]
0x2CE3 Power Deadband F005 1 R/W 2 [0 , 65535]
0x2CE5 Energy Deadband F005 1 R/W 2 [0 , 65535]
0x2CE7 Other Deadband F005 1 R/W 2 [0 , 65535]
0x2CE9 Msg Fragment Size F005 1 R/W 2 [30 , 2048]
0x2CEB Binary Input Block 1 F012 1 R/W 1 0=NOT USED
1=CTL EVENTS 1-16
2=CTL EVENTS 17-32
Ajustes DNP 3.0 Esclavo 1 - DNP 3.0 Slave 1 Settings(cont.)
3=CTL EVENTS 33-48
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
