B-96 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
4=CTL EVENTS 49-64
5=CTL EVENTS 65-80
6=CTL EVENTS 81-96
7=CTL EVENTS 97-112
8=CTL EVENTS 113-128
9=SWITCHGEAR 1-8
10=SWITCHGEAR 9-16
11=BOARD F 1-16
12=BOARD F 17-32
13=BOARD G 1-16
14=BOARD G 17-32
15=BOARD H 1-16
16=BOARD H 17-32
17=BOARD J 1-16
18=BOARD J 17-32
0x2CEC Binary Input Block 2 F012 1 R/W 1 0=NOT USED
1=CTL EVENTS 1-16
2=CTL EVENTS 17-32
3=CTL EVENTS 33-48
4=CTL EVENTS 49-64
5=CTL EVENTS 65-80
6=CTL EVENTS 81-96
7=CTL EVENTS 97-112
8=CTL EVENTS 113-128
9=SWITCHGEAR 1-8
10=SWITCHGEAR 9-16
11=BOARD F 1-16
12=BOARD F 17-32
13=BOARD G 1-16
14=BOARD G 17-32
15=BOARD H 1-16
16=BOARD H 17-32
17=BOARD J 1-16
18=BOARD J 17-32
0x2CED Binary Input Block 3 F012 1 R/W 1 0=NOT USED
1=CTL EVENTS 1-16
2=CTL EVENTS 17-32
3=CTL EVENTS 33-48
4=CTL EVENTS 49-64
5=CTL EVENTS 65-80
6=CTL EVENTS 81-96
7=CTL EVENTS 97-112
8=CTL EVENTS 113-128
9=SWITCHGEAR 1-8
10=SWITCHGEAR 9-16
11=BOARD F 1-16
12=BOARD F 17-32
13=BOARD G 1-16
14=BOARD G 17-32
15=BOARD H 1-16
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
