B-112 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
11=BOARD F 1-16
12=BOARD F 17-32
13=BOARD G 1-16
14=BOARD G 17-32
15=BOARD H 1-16
16=BOARD H 17-32
17=BOARD J 1-16
18=BOARD J 17-32
0x2DB8 Binary Input Block 10 F012 1 R/W 1 0=NOT USED
1=CTL EVENTS 1-16
2=CTL EVENTS 17-32
3=CTL EVENTS 33-48
4=CTL EVENTS 49-64
5=CTL EVENTS 65-80
6=CTL EVENTS 81-96
7=CTL EVENTS 97-112
8=CTL EVENTS 113-128
9=SWITCHGEAR 1-8
10=SWITCHGEAR 9-16
11=BOARD F 1-16
12=BOARD F 17-32
13=BOARD G 1-16
14=BOARD G 17-32
15=BOARD H 1-16
16=BOARD H 17-32
17=BOARD J 1-16
18=BOARD J 17-32
0x2DB9 Default Analog Map F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x2DBA Analog Input Point 0 F004 1000 R/W 1 [0 , 32767]
0x2DBB Analog Input Point 1 F004 1000 R/W 1 [0 , 32767]
0x2DBC Analog Input Point 2 F004 1000 R/W 1 [0 , 32767]
0x2DBD Analog Input Point 3 F004 1000 R/W 1 [0 , 32767]
0x2DBE Analog Input Point 4 F004 1000 R/W 1 [0 , 32767]
0x2DBF Analog Input Point 5 F004 1000 R/W 1 [0 , 32767]
0x2DC0 Analog Input Point 6 F004 1000 R/W 1 [0 , 32767]
0x2DC1 Analog Input Point 7 F004 1000 R/W 1 [0 , 32767]
0x2DC2 Analog Input Point 8 F004 1000 R/W 1 [0 , 32767]
0x2DC3 Analog Input Point 9 F004 1000 R/W 1 [0 , 32767]
0x2DC4 Analog Input Point 10 F004 1000 R/W 1 [0 , 32767]
0x2DC5 Analog Input Point 11 F004 1000 R/W 1 [0 , 32767]
0x2DC6 Analog Input Point 12 F004 1000 R/W 1
[0 , 32767]
Ajustes DNP 3.0 Esclavo 3 - DNP 3.0 Slave 3 (cont.)
0x2DC7 Analog Input Point 13 F004 1000 R/W 1 [0 , 32767]
0x2DC8 Analog Input Point 14 F004 1000 R/W 1 [0 , 32767]
0x2DC9 Analog Input Point 15 F004 1000 R/W 1 [0 , 32767]
0x2DCA Analog Input Point 16 F004 1000 R/W 1 [0 , 32767]
0x2DCB Analog Input Point 17 F004 1000 R/W 1 [0 , 32767]
0x2DCC Analog Input Point 18 F004 1000 R/W 1
[0 , 32767]
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
