APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-113
0x2DCD Analog Input Point 19 F004 1000 R/W 1 [0 , 32767]
0x2DCE Analog Input Point 20 F004 1000 R/W 1 [0 , 32767]
0x2DCF Analog Input Point 21 F004 1000 R/W 1 [0 , 32767]
0x2DD0 Analog Input Point 22 F004 1000 R/W 1 [0 , 32767]
0x2DD1 Analog Input Point 23 F004 1000 R/W 1 [0 , 32767]
0x2DD2 Analog Input Point 24 F004 1000 R/W 1 [0 , 32767]
0x2DD3 Analog Input Point 25 F004 1000 R/W 1 [0 , 32767]
0x2DD4 Analog Input Point 26 F004 1000 R/W 1 [0 , 32767]
0x2DD5 Analog Input Point 27 F004 1000 R/W 1 [0 , 32767]
0x2DD6 Analog Input Point 28 F004 1000 R/W 1 [0 , 32767]
0x2DD7 Analog Input Point 29 F004 1000 R/W 1 [0 , 32767]
0x2DD8 Analog Input Point 30 F004 1000 R/W 1 [0 , 32767]
0x2DD9 Analog Input Point 31 F004 1000 R/W 1 [0 , 32767]
0x2DE0 Confirmation address W 1
Miscelaneous Settings
0x2DE2 Relay Out Of Service F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x2DE3 Local/Remote Blocked F012 1000 R/W 1 0=OFF
1=ON
0x2DE4 Active Language F004 1000 R/W 1 [0 , 1]
0x2DF5 Confirmation address W 1
Ajustes Unidad Sobreintensidad Instantánea de Tierra Aislada Grupo 1 - Isolated Ground IOC 1 Settings
0x2DF6 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2DF7 Vh Level F003 1 R/W 2 [2 , 70] V
0x2DF9 Il LEVEL F003 1 R/W 2 [0.005 , 0.400] A
0x2DFB Vl LEVEL F003 1 R/W 2 [2 , 70] V
0x2DFD Ih LEVEL F003 1 R/W 2 [0.005 , 0.400] A
0x2DFF Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2E01 Time to inst F003 1 R/W 2 [0.00 , 900.00] s
0x2E03 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2E16 Confirmation address W 1
Ajustes Unidad Sobreintensidad Instantánea de Tierra Aislada Grupo 2 - Isolated Ground IOC 2 Settings
0x2E17 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2E18 Vh Level F003 1 R/W 2 [2 , 70] V
0x2E1A Il LEVEL F003 1 R/W 2 [0.005 , 0.400] A
0x2E1C Vl LEVEL F003 1 R/W 2 [2 , 70] V
0x2E1E Ih LEVEL F003 1 R/W 2 [0.005 , 0.400] A
0x2E20 Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2E22 Time to inst F003 1 R/W 2 [0.00 , 900.00] s
0x2E24 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2E37 Confirmation address W 1
Ajustes Unidad Sobreintensidad Instantánea de Tierra Aislada Grupo 3 - Isolated Ground IOC 3 Settings
0x2E38 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2E39 Vh Level F003 1 R/W 2 [2 , 70] V
0x2E3B Il LEVEL F003 1 R/W 2
[0.005 , 0.400] A
