APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-117
3=IEC Curve A
4=IEC Curve B
5=IEC Curve C
6=IEC Long-Time Inv
7=IEC Short-Time Inv
8=IAC Ext Inv
9=IAC Very Inv
Ajustes Sobreintensidad Temporizada de Fases Nivel Alto Grupo 2 - Phase TOC Low 2 Settings(cont.)
10=IAC Mod Inv
11=ANSI Ext Inv
12=ANSI Very Inv
13=ANSI Norm Inv
14=ANSI Mod Inv
15=I2t
16=Definite Time
17=Rectifier Curve
18=User Curve A
19=User Curve B
20=User Curve C
21=User Curve D
0x32C7 TD Multiplier F003 1 R/W 2 [0.00 , 900.00] s
0x32C9 Reset F012 1 R/W 1 0=INSTANTANEOUS
1=LINEAR
0x32CA Voltage Restraint F012 1 R/W 1 0=DISABLED
1=ENABLED
0x32CB Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x32DE Confirmation address W 1
Ajustes Sobreintensidad Temporizada de Fases Nivel Alto Grupo 3 - Phase TOC Low 3 Settings
0x32DF Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x32E0 Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x32E1 Pickup Level F003 1 R/W 2
[0.05 , 160.00] A
0x32E3 Curve F012 1 R/W 1 0=IEEE Ext Inv
1=IEEE Very Inv
2=IEEE Mod Inv
3=IEC Curve A
4=IEC Curve B
5=IEC Curve C
6=IEC Long-Time Inv
7=IEC Short-Time Inv
8=IAC Ext Inv
9=IAC Very Inv
10=IAC Mod Inv
11=ANSI Ext Inv
12=ANSI Very Inv
13=ANSI Norm Inv
14=ANSI Mod Inv
15=I2t
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
